Universal Wear Tester(UWT)/Stoll Quartermaster
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Universal Wear Tester (UWT) is used to determines the wear and abrasion resistance of fabric used in clothing, footwear and industrials. Supplied with surface abrasion head (inflated diaphragm method, flex abrasion head, depth abrasion test device, flat abrasion (frosting) and pilling test device as well as necessary weights and initial supply of abrasive. Fitted with built-in timer and mechanical cycle counter.
Standard Test
ASTM Standards: D3514. D3885. D3886 (textile, coating, and plastic wear resistance)
AATCC Standards: 119. 120 (fabric abrasion and pilling resistance)
FTMS Standards: 191/5300/5302 (federal textile durability protocols)
FORD Standards: EFB 15J2. BN 112-01 (automotive interior material testing)
JIS L1096-1999(A)
CNS 12915-1991
Feature
Dual Abrasion Heads: Includes surface abrasion head (inflated diaphragm method) and flex abrasion head for diverse testing modes.
Interchangeable Accessories: Compatible with weights, blades, and sample holders to simulate real-world wear scenarios.
Advanced Control System: LCD interface with programmable cycles, stroke length, and speed settings; real-time progress display.
Uniform Testing Conditions: Motor-driven 120 RPM speed and 25mm stroke length guarantee standardized results across operators.
Enhanced Clamping Mechanism: Securely tensions samples to prevent slippage during high-speed reciprocation.
Liquid Immersion Capability: Test samples under wet conditions (water, oil, solvents) to simulate extreme environments.
Parameters
| Parameter | Specification |
|---|---|
| Rotational Speed | 120 RPM (fixed) |
| Stroke Length | 25 mm (fixed) |
| Test Modes | Flat/curved/edge/fold abrasion, frosting, pilling |
| Sample Compatibility | Fabrics, plastics, leather, rubber, paper, coated materials |
| Power Supply | 220/110V, 50/60Hz |
| Dimensions | 570 (W) × 680 (D) × 400 (H) mm |
| Net Weight | 80 kg |
| Cycle Counter | Mechanical (1–999.999 cycles) |
| Air Injection System | Adjustable pressure for diaphragm inflation |
