Fabric ici pilling and snagging box
Applications
A universal pilling and snagging tester drives system to rapidly repeat pilling or snagging on fabrics to generate normal wear on samples in a fraction of the time.
Provided with unique controller allowing selection between standard and several optional speed settings.
Programmable reversing function at 30 rpm and test cycle definition facilities.
Standards
ISO 12945-1:2021 Textiles — Determination of pilling and fuzzing (ICI box method)
BS 5811:1979+A1:1991 British Standard for Pilling of Textiles
GB/T 4802.3-2008: Chinese National Standard for Pilling Test of Textile Fabrics
JIS L1076:2019: Japanese Standard for Pilling of Textiles
Features
Multi-station configuration: Equipped with 4 pilling boxes, allowing simultaneous testing of multiple samples to improve efficiency;
Flexible operation: Supports forward and reverse rotation, better simulating actual fabric friction scenarios;
Adjustable parameters: Rotational speed covers multiple gears from 20 to 70 rpm, adapting to different testing standards;
Intelligent display and alerts: LCD screen displays parameters in real time, and an alarm sounds automatically upon test completion;
Reliable design: The pilling boxes are well-sealed (ensuring testing stability), and the motor has an automatic pause protection function;
Multi-standard compatibility: Compatible with mainstream pilling test standards such as ISO/BS/GB/JIS, suitable for testing various textiles.
Technical Parameters
| Box Number | 2. 4. 6 | ||
| Control Method | Touch Screen Control | ||
| Speed | 60±2r/min（30~70can be set） | ||
| Box Inside Dimension | （235×235×235）mm | ||
| polyurethane sample tube | Length 140mm，Outer diameter(31.5±1)mm，thickness(3.2±0.5)mm, mass (52.25±1)g，4pcs for a box | ||
| Counter | 1~99999cycles | ||
| ICI pilling test method | GB/T 4802.3. ISO 12945.1. BS 5811. JIS L1076 | ||
| Power | AC 220V 50Hz 120W | ||
| Dimension/Weight(cm/kg) | 82*42*55/40 | 82*42*85/60 |
98*51*120/142 |
