Fabric Fiber Shedding Degree Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Applications
The Fabric Fiber Shedding Degree Tester (Friction) is suitable for sheet textile products such as curtain materials. It is used to measure the total visible light transmittance of the fabric to evaluate its light-blocking performance.
Standards
JIS L1005-2009 ：Textiles - Determination of light transmittance of sheet textile products
Features
Touch screen controller: The number of frictions can be set arbitrarily.
Backup mechanical buttons for buttons in the touch screen: They can be used simultaneously, which is convenient and fast.
Pneumatic holder for specimen installation: Convenient and fast.
Equipped with a calender for adjusting the moisture content of the abrasive: The roll-off rate can be adjusted.
Complies with the standard: Appendix A of GB/T 40270 - 2021
Technical Parameters
| Parameter | Specification |
|---|---|
| Stroke of the friction head | (200 ± 2) mm |
| Reciprocating speed | 30 times/min |
| Diameter of the circular friction head | (90 ± 1) mm |
| Outer diameter of the fixed clamp ring of the friction head | (120 ± 0.5) mm |
| Inner diameter of the fixed clamp ring of the friction head | (90 ± 0.5) mm |
| Diameter of the test washer | (113 ± 0.5) mm |
| Foam plastic washer | Diameter 105 mm, thickness 8 mm, unit area mass approximately 270 g/m² |
| Total mass of the friction load | (595 ± 7) g |
| Sandpaper | 600 - grit aluminum oxide water - washable sandpaper |
| Power supply | AC 220V, 50Hz |
Send product request
