Thermal Radiation Performance Tester(RPP)

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The RPP test is mainly used to determine the radiant thermal protection performance of thermal protective clothing. Since thermal radiation is one of the main heat transfer forms that cause thermal damage. The method can better test and evaluate the thermal protection performance of thermal protective clothing from one aspect, and has been widely used in the field of forest fire.

Standards:

NFPA 1971. NFPA 2112. BS EN ISO 6942. EN 366. ASTM F2702. ASTM F1939

Features:

◆Evaluation of flame retardant properties of flame retardant materials

◆Detect abnormalities and reduce accidents

◆Calculate the RPP value

◆Evaluate thermal protection performance

◆Improve job safety

◆Improve the quality control system

Technical Parameters:

Items Parameters
Heating power 6.5Kw/220V/50Hz
Heating length 178mm, diameter 8mm
Heat flux density 10Kw/m2-80Kw/m2
Radiation source temperature control -1200℃±5℃
Thermal radiation source temperature sensor Thermocouple (0 ℃ -1600 ℃)
Calorimeter heat capacity 480.937J/K
Heating area 50mm2×50mm2
Calorimeter temperature range -80℃
Test environment

Between 15 ℃ -35 ℃ ,the room without air circulation
