Seat Thermal Manikin
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Automotive seat thermal comfort and humidity management testing
Truck seat heat performance evaluation
Office chair long-term comfort and heat dissipation testing
Aircraft seat thermal comfort and cooling/ventilation performance assessment
Heated seat performance testing
Seat material thermal conductivity verification
Automotive seat design and ergonomic research
Passenger environment thermal comfort optimization and HVAC system evaluation
Standards
GB/T 18830-2009: Test methods for automotive seat and backrest thermal comfort
SAE J826: Human engineering H-point measurement standard
ISO 14505-2: Seat thermal comfort testing — Thermal manikin method
ISO 12894: Anthropometry and application of human models
ISO 9920: Clothing, personal protective equipment, and seat thermal comfort assessment
ASTM F1291: Standard method for evaluating thermal comfort using thermal manikins
ASTM F2370: Measurement of seat heat/cooling energy and humidity transfer
EN 12127: Automotive seat heat flux and pressure distribution measurement
Note: Some standards apply to overall seat thermal comfort evaluation, while others relate specifically to heat flux, humidity, or heated/ventilated seat energy transfer.
Product Specifications
| Category | Parameter | Technical Specification |
|---|---|---|
| Manikin Type | 50th percentile adult male, Back + Buttocks/Thighs | Based on SAE J826 HPM-II |
| Thermal Zones | 8 independently controlled zones | Each zone with temperature control protection |
| Shell Material | Heat-conductive carbon fiber | Embedded heating wires and sensors |
| Temperature Control Range | 10–40°C | ±0.1°C accuracy |
| Max Power Output | — | 1500 W/m² |
| Sweat Output Range | — | 0–1000 ml/hr/m² |
| Continuous Heat Dissipation | — | 350 W/m² |
| Power Accuracy | — | ±1% |
| Humidity Measurement Accuracy | — | ±3% RH |
| Power Supply | — | 208–265 VAC, 50/60Hz, Single Phase |
| Cooling Water | — | Temp-controlled chiller, 30°C, 500 W, 2 L/min, 15 PSI |
| Weight | — | Approx. 120 kg (without water cooling system) |
| Dimensions | — | 1189 × 575 × 856 mm |
