Fabric UV resistance tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Fabric UV Resistance Tester is designed to simulate solar UV radiation and evaluate the ultraviolet protection performance of textiles, sun-protection products, and cosmetics. The instrument replaces in-vivo testing, providing accurate SPF measurement, UVA/UVB analysis, and critical wavelength evaluation. It combines a stable UV-visible light source, spectrophotometric detection, and powerful data analysis software, offering fast, economical, and reproducible testing.
Standards
AATCC 183 – Determination of SPF for textiles
AS/NZS 4399 – Sun Protective Clothing Standard
ISO 24443 – In vitro determination of sunscreen UVA protection
Colipa 2011 – European sunscreen testing standard
FDA – Sun protection product guidance
Other international UV protection standards
Technical Parameters
| Parameter | Specification |
|---|---|
| Spectral Range | 290–400 nm (UVA & UVB) |
| Wavelength Repeatability | 0.25 nm |
| Monochrome Resolution | 1.66 nm |
| Wavelength Accuracy | ±0.2% |
| Light Source | 125 W Xenon arc lamp |
| Light Stability | High stability, uniform irradiation |
| Data Storage | Cumulative up to 36 tests |
| Sampling Points | 12 points, automatic scanning |
| Automatic Test | Yes, continuous test with auto-stop |
| Software Functions | UPF, UVA, UVB, MPF, critical wavelength, Boots Star rating, absorbance |
| Calibration | NIST traceable kit |
| External Dimensions | 460 × 320 × 350 mm |
| Power Supply | 220V AC, 50Hz |
| Weight | 80 kg |
