Taber Shear Scratch Tester (Scratch & Mar)
Get a quote：
Web: qinsun-lab.com
Email：info@qinsun-lab。com
Standards:
GB/T 2918.GB/T 6151.GB/T 8424.3.PV3952.BMW GS97034-2.BMW GS97034-9.GMN 3943-2003.FLTM BN 108-13.STD1024-3113.GMW 14698-A，GMW 14688
Application:
Scratch tester used for a variety of automotive interior materials, such as plastics, rubber, leather, fabric, coating materials, coating materials and other non-composite materials such as scratch resistance detection.
Technical Parameters:
1. The travel range: 10-200mm;
2. Speed range: 10-200mm / s;
3. Speed Buffer: 10 ± 1mm;
4. The metal scraper head diameter: 0.5mm, 0.75mm, 1mm (Erichsen318), 3mm, 5mm, 7mm;
5. The metal scraper head material: tungsten carbide;
6. Pressurized weight and scraping components total weight: 2N, 3N, 5N, 7N, 8N, 10N, 12N, 15N, 20N(optionally with option) mass error does not exceed 1%;
7. Plastic scraper means: polymethyl methacrylate (PMMA);
a. Diameter 16mm thickness of 1mm;
b. scraping means is an edge radius of 0.5mm;
c. Hardness shore D85.
8. Power: AC220V ± 10%, 50Hz.
