Reciprocating Abraser
Get a quote：
Web: qinsun-lab.com
Email：info@qinsun-lab。com
Fixed sample on a horizontal table, wearing it under the specified abrasive and load with the horizontal movement of the platform. According to the principle of the lever, the other end of the test arm fits the hammer to maintain the balance of the test arm, making ensure the accuracy of the sample surface load and the reliability of the test results. The height of abrasive and load is adjustable, meeting the need of different height samples. In addition, use different friction mediums to test the wear resistance of different products according to the different requirements of customers.
Standards
1. ASTM F2496 Standard practice for determining the scratch hardness and scrape Adhesion of prints and coatings active standard.
2. ISO 1518-1 Paints and varnishes - Determination of scratch resistance - Part 1: Constant-loading method.
3. ISO1518-2 Paints and varnishes - Determination of scratch resistance - Part 2: Variable-loading method.
4. GME 60248 Paint elasticity and textile interiors material-Resistance to scratching.
5. D44 1221 Fluff surface material-Resistance to scraping by abrasion.
6. D14 1055-2004 Materials and organic coatings-wear by rubbing.
7. D42 Inside and outside plastic parts-Resistance to scratching by abrasion.
Technical Parameters
| Items | Parameters |
| Stroke range | 6-120mm, adjustable |
| Speed range | 1-100 reciprocating/min, stepless adjustable |
| Weight | Approximately 48.5kg |
| Dimension | 532mm*471mm*630mm（W*D*H） |
| Power | 220V, 50HZ, 1A |
