Solar Simulator and Test Bench
Get a quote：
Web: qinsun-lab.com
Email：info@qinsun-lab。com
TheSolar Simulator and Test Benchis a high-precision laboratory device designed to simulate natural sunlight for testing solar products such as solar cells, photovoltaic modules, and light-sensitive materials. You can use it to replicate solar intensity, spectral distribution, and illumination under various environmental conditions, including different latitudes, seasons, and weather. Its high uniformity, stability, and adjustable irradiance make it ideal for R&D, production, and quality control in the solar industry, providing accurate and reproducible data.
Standards
(1) IEC 60904-9 – Photovoltaic Devices: Requirements for Solar Simulators
(2) ASTM E927 – Laboratory Simulation of Solar Radiation
(3) IEC 60904-3 – Measurement of Photovoltaic Current-Voltage Characteristics
(4) ISO 9060 – Solar Irradiance Measurement Standards
(5) ASTM G173 – Reference Solar Spectra for Testing
Technical Parameters
| Parameter | Details |
|---|---|
| Light Source Type | Short-arc high-pressure xenon lamp |
| Light Source Lifetime | 1000h+ |
| Light Source Warranty | 800h |
| Number of Light Sources | Matched according to irradiation area and irradiance |
| Irradiation Area | D100mm, D300mm, D500mm, D600mm, D700mm, D900mm (custom sizes available) |
| Maximum Irradiance in Effective Spot | ≥9W/mm² |
| Minimum Irradiance in Effective Spot | ≥2W/mm² |
| Average Irradiance in Effective Spot | ≥4W/mm² |
| Focus Distance | ≤2m |
| Reflector Aperture | - For D300mm irradiation area: ≥300mm- For D600mm irradiation area: ≥500mm- For D900mm irradiation area: ≥890mm |
| Spectral Range | 300–1700nm (optimized) |
| Light Emission Direction | Horizontal output |
| Spectral Matching Degree | Grade A (AM1.5G) |
| Instability | LTI ≤ ±2%; Grade A |
| Equipment Dimensions | Approximately 4m × 1.5m × 2.6m (L×W×H) |
| Arrangement | For ≥13 lamp heads: at least 1 head faces directly forward, with outer heads evenly distributed around the perimeter |
