Material Surface Performance Comprehensive Tester

Get a quote:

Web: qinsun-lab.com

Email:serving@qinsun-lab。com

The Material Surface Performance Comprehensive Tester is a modular instrument designed for high-precision evaluation of material and component surface mechanical properties, including coatings and platings. The instrument can test friction force, friction coefficient, wear volume, and coating thickness under varying loads, sliding speeds, media conditions (e.g., lubricating oil, saline), and environmental temperatures. It supports multiple friction modes, including rotational, reciprocating, ring-on-block, and pipe surface friction. Its modular design allows flexible installation and combination, high automation, and user-friendly operation, making it suitable for materials science research, industrial product development, and quality control.

Application

Mechanical property testing of metal, ceramic, polymer, and composite material surfaces.

Wear and friction performance evaluation of coatings, platings, thin films, and composite materials.

Friction and wear testing under low-temperature conditions.

Friction and wear testing in liquid media environments (e.g., lubricating oil, saline).

Material development, quality control, and tribology research in industrial production and laboratories.

Standards

GB/T 3960-2016 Plastics – Determination of Sliding Wear Properties

GB/T 20394-2013 Artificial Turf Durability Test Method

JB/T 8554-1997 Coating Adhesion Automatic Scratch Test Method

ASTM G99 Standard Test Method for Wear Testing with a Pin-on-Disk Apparatus

ASTM G133 Standard Test Method for Linearly Reciprocating Pin-on-Flat Sliding Wear

ISO 20502 Coating Scratch Test

DIN 50324 Friction and Wear Test Standard

Parameters

ParameterSpecification
Reciprocating Friction Load: 30–1000 g (weight), 10–200 N (automatic); accuracy 0.2% F.S.; sliding frequency 0.1–45 Hz; stroke 0.5–25 mm; max reciprocating force ≤100 N
Electrochemical Reciprocating Friction Load: 30–1000 g (weight), 10–50 N (automatic); accuracy 0.2% F.S.; frequency 0.1–5 Hz
Rotational Friction Load: 30–1000 g (weight), 10–200 N (automatic); accuracy 0.2% F.S.; table speed 5–2800 rpm, stepless
Ring-on-Block Friction Load: 100–1000 g (weight), 10–200 N (automatic); accuracy 0.2% F.S.; spindle speed 5–2000 rpm, stepless
Pipe Surface Friction Load: 50–1000 g (weight); accuracy 0.2% F.S.; reciprocating stroke 0.5–20 mm; frequency 0.1–35 Hz
Wear Volume Measurement Load ≤40 g; wear scar depth ±0.5 mm; accuracy 0.02 µm (customizable)
Low-Temperature Module Load 0.3–10 N; accuracy 0.2% F.S.; temperature range: room temperature to -50℃
Power Supply 220 V, 50 Hz, 6000 W
Instrument Weight Approx. 150 kg
Workbench Size 1800 × 750 × 800 mm (user-supplied)

Features

Modular Design: Quick combination of rotational, reciprocating, ring-on-block, and pipe friction modules.

Wide Load and Sliding Speed Range: Meets friction and wear testing needs for different materials and environments.

High-Precision Wear Measurement: Automatically calculates wear depth and generates 2D contour plots.

Low-Temperature and Electrochemical Modules: Simulate special environments to closely match actual applications.

Automated Control System: Real-time display of friction force, friction coefficient, wear volume, and environmental parameters; data can be stored, printed, and analyzed.

User-Friendly Interface: Simplifies parameter setting, monitoring, and safety management.
