Humidifying Bottle Performance Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The humidifier bottle performance tester is mainly used to detect various properties of humidifier bottles, including but not limited to leakage, pressure - resistance, humidification output, and overflow. This instrument can ensure the safety and effectiveness of humidifier bottles during use, and it is an important tool for the quality inspection of medical oxygen humidifiers.
Standards
YY/T 1610 - 2018：Anaesthetic and respiratory equipment - Oxygen humidifiers for medical use
Features
• Supports leakage, pressure resistance, humidification output, and overflow testing functions for humidification bottles.
• 7-inch color touchscreen control and intuitive interface significantly enhance the user experience.
• The device is equipped with a miniature printer for real-time printing of test results.
• Equipped with a high-precision pressure sensor, allowing for stable control of output pressure via a rotary pressure knob.
• Equipped with a high-precision flow meter for accurate measurement of flow rate through the tubing.
• Features a 20° tilt design device to accommodate observation at various angles for different specifications.
• Utilizes a universally designed conical test interface to meet the testing requirements of most products on the market.
• The device has a powerful data storage function, capable of storing up to 50.000 data entries.
• Miniature printer and universal USB data interface facilitate data output and transfer.
• Intelligent features such as overload protection and power-off memory effectively ensure user safety.
• Optional GMP "Computerized Systems" compliant testing software is available, featuring user management, permission management, and data audit trail functions.
Technical Parameters
| Parameter | Specification |
|---|---|
| Working Range | Usually between 0 and 1000KPa; some models may offer higher pressure options (e.g., 2000KPa or 2500KPa) |
| Flow Accuracy | ±1%, ensuring the accuracy of testing |
| Power Supply | Generally 220V, 5A, 50Hz |
| Instrument Operating Voltage | Usually 220V |
| Air Source Requirements | Adjustable from 0 to 2MPa; the air source needs to be provided by the user |
| Main Unit Dimensions | Vary depending on the model; e.g., some models: 570×400×200mm (Length×Width×Height) |
| Other Functions | Some advanced-model humidifier bottle performance testers may have features like micro-computer control, large touch-screen display, Chinese menu settings, digital preset test flow, and printing function (making operation more intuitive and convenient) |
Accessoriess
Standard configuration: electronic control unit, testing unit, printer
