Benchtop tracking index tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The Tracking Tester is suitable for testing the tracking resistance of various solid insulating materials, including:
Electronics Industry: Evaluates tracking performance of electrical components, circuit boards, and insulating materials.
Power Industry: Assessment of electrical insulating materials for cables, switches, transformers, and related equipment.
Plastics: Testing of plastic products, insulating coatings, and electronic plastic housings.
Automotive Industry: Evaluation of tracking resistance of automotive electrical systems, batteries, and electronic components.
Construction Industry: Testing electrical materials for building applications, including cables, distribution boxes, and sockets.
Household Appliances: Insulation performance testing for wires, batteries, plugs, and other electrical components.
R&D and Quality Control: Verification of new materials and ongoing product quality monitoring.
Standards
The tester complies with the following national, industry, and international standards:
GB/T 4207-2003: Determination of comparative and proof tracking indices of solid insulating materials under wet conditions
IEC 60112: Test methods for electric strength and tracking resistance of solid insulating materials
UL 746A: Plastic Materials – Short Term Property Evaluations
IEC 60216: Thermal aging tests for electrical insulating materials
ASTM D2344: Standard methods for insulation material aging tests
IEC 60529: Degrees of protection provided by enclosures for electrical equipment
GB/T 5169: Safety testing standards for electrical products
Accessories and Consumables
| Accessory | Quantity | Description |
|---|---|---|
| Electrode assembly | 1 | Tungsten steel test electrode + stainless steel rod, compliant with specifications |
| Droplet device | 1 | Ensures precise droplet application, adjustable droplet volume |
| Droplet container | 1 | For test solution, supports accurate droplet control |
| High-precision flow meter | 1 | Ensures uniform and precise droplet volume |
| Gas interface | 1 | For connection to user-supplied gas source (e.g., LPG) |
| Specimen holder | 1 | Supports different shapes and sizes, ensures stability |
| Temperature sensor | 1 | Measures and controls temperature during testing |
Test Principle
The Leakage Current / Tracking Tester applies voltage across the surface of solid insulating materials while dripping a defined concentration of liquid (e.g., NH4Cl solution) between electrodes. The combination of electric field, voltage, current, and droplet count simulates surface tracking and erosion phenomena. The tester measures tracking onset time and damage depth, evaluating the material’s durability and safety in humid electrical environments.
Operating Instructions
Specimen Preparation: Secure the specimen in the holder, ensuring good contact with electrodes.
Parameter Setting: Set droplet interval, voltage, current, and droplet count using the touch screen.
Start Test: Press “Start”; the device automatically initiates droplet application and voltage.
Record Results: The system automatically records all test data during the process.
Test Completion: After testing, the device shuts off voltage, stops droplet application, and exhausts fumes. Results are saved and can be stored for analysis.
Safety Precautions
Ensure the equipment is powered off before cleaning or maintenance.
Avoid touching electrodes and specimen holder during testing to prevent electric shock.
Ensure stable gas connection and shut off gas after testing.
