Rubber Test Dummy for Safety Compliance Testing
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
Performance testing of fall protection safety harness systems
Performance evaluation of harness systems for guardrail work
Verification of area-restricted safety harness systems
Rescue harness performance testing
Dynamic and static load testing of safety harnesses
Safety inspection for construction and industrial high-altitude work
Verification of safety harness products in testing laboratories and inspection agencies
Standards
GB6095-2021 Fall Protection Safety Harness
GB/T6096-2020 Fall Protection Safety Harness System Performance Test Methods
GB6095-2009 Safety Harness
GB/T6096-2009 Safety Harness Test Methods
Product Specifications
| Item | Technical Parameters |
|---|---|
| Dummy Weight | 100 ± 2 kg, 136 ± 2 kg |
| Surface Hardness | >90 HD |
| Rubber Thickness | ≥40 mm |
| Number of Attachment Points | 4 (1 each for left and right hands, 1 head, 1 crotch) |
| Attachment Material | 304 Stainless Steel M16 Lifting Rings |
| Key Dimensions | Shoulder width: 483 mm, Hip width: 400 mm, Leg circumference: 150 mm, Neck circumference: 150 mm, Leg spacing: 50 mm |
| Exterior Material | Molded as a single internal structure, integrated outer rubber layer |
| Surface | Smooth transitions to avoid metal contact interfering with tests |
Accessories and Consumables
| Accessory/Consumable | Description |
|---|---|
| Lifting Rings | 4 × M16 304 stainless steel rings (1 each for left and right hands, 1 head, 1 crotch) |
| Flat Lifting Straps | For connecting the harness to the dummy |
| U-Shaped Shackles | For harness fixation, adaptable to different test scenarios |
| Sensor Connectors | For data acquisition in dynamic load testing |
| Rubber Protective Covers | Prevent metal contact from affecting test results |
Testing Principle
The safety harness test dummy simulates human weight, size, and joint attachment points to perform stress tests on harness systems under dynamic and static conditions. During the experiment, the dummy is hung on the test frame and subjected to predetermined loads or fall forces. This tests the harness’s load capacity, slip behavior, and overall structural reliability. Sensors monitor force in real time, and when preset values are reached or damage occurs, the experiment is recorded and can automatically stop to ensure safety.
