Automated blade sharpness tester machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Quality Control in Medical Device Manufacturing: In medical device manufacturing enterprises, the Sharpness Tester for Surgical Blades is used to conduct quality inspections on surgical blades. By simulating the cutting process in surgery and measuring the force required for the blade to cut through standard suture lines or other test materials, it assesses whether the sharpness of the blade meets relevant standard requirements. Only products with qualified sharpness can enter the market, thus ensuring the quality and safety of surgical instruments and providing a guarantee for the smooth progress of surgeries.
- Inspection and Selection by Medical Institutions: Medical institutions such as hospitals also use the sharpness tester for surgical blades to regularly inspect the sharpness of surgical blades. This helps doctors understand the performance of the blades before surgery, select the most suitable surgical instruments, improve surgical efficiency, reduce tissue damage and patient pain during surgery, and at the same time, lower the risks of postoperative infections and complications.
- Quality Inspection in Tool Manufacturing: In tool manufacturing enterprises, the sharpness tester for surgical blades can be used to test the sharpness of blades of different types and uses, ensuring that each batch of blades has stable sharpness performance to meet users' needs.
- Product R & D and Improvement: The sharpness tester for surgical blades is also used in the R & D process of cutting tools. Manufacturers can test blades made of different materials, with different processes and designs, collect relevant data, analyze the relationship between sharpness and materials, processes, etc., so as to optimize product design, improve the sharpness and durability of blades, and launch more competitive products.
- Teaching Practice and Training: In the teaching practice of relevant majors, the sharpness tester for surgical blades is an important teaching tool. It can help students intuitively understand the concept and testing methods of blade sharpness, and cultivate students' practical operation ability and scientific thinking.
Standards
YY 0174 - 2019： Surgical Blades
Technical Parameters
| Parameter | Specification |
|---|---|
| Testing Range | Force value testing range: 0.1N - 10.0N; error does not exceed ±0.01N |
| Blade Types | Capable of testing various surgical blade specifications, including straight knives, circular knives, and angled ophthalmic knives |
| Testing Rate | Testing speed usually ≤ 10mm/s; error range within ±1mm/min; testing speed can be set via software |
| Other Functions | 1. Equipped with high-precision sensors & measurement system (accurately measures force/displacement in cutting process); 2. Adopts PLC/ARM technology for intelligent operation; 3. Equipped with programmable controller & touch-screen interface (convenient for parameter setting/operation); 4. Displays applied pressure & test data in real time (facilitates observation/analysis); 5. Built-in Chinese-English bilingual input function (suitable for domestic & foreign users) |
Accessoriess
1. One main unit
2. One roll of printing paper
3. One set of clamps
4. One 100g weight
5. One year (warranty)
6. Operating instructions
7. Free lifetime instrument upgrade service according to standard specifications
