Custom fully automatic falling sand abrasion tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
You can use this tester to assess:
Wear resistance of anodized films on aluminum and aluminum alloys
Abrasion performance of organic polymer coatings and composite coatings
Consistency verification of metal surface treatment processes
Factory inspection and type testing of coated products
Material performance research in third-party laboratories and research institutions
Standards
YS/T 1186-2017: Falling Sand Tester Type B for Anodized Aluminum and Organic Polymer Coatings
Technical Specifications
| Item | Specification |
|---|---|
| Conduit Length | 914 mm |
| Conduit Inner Diameter | 19 mm |
| Hopper Volume | 2.3 L |
| Dimensions (L × W × H) | 900 × 520 × 1900 mm |
| Total Weight | 75 kg |
Accessories
| Name | Description |
|---|---|
| Falling Sand Conduit | Controls abrasive drop height and direction |
| Abrasive Hopper | Stores and evenly releases abrasives |
| Sample Fixture | Secures the test sample |
| Standard Abrasive | Abrasives that meet testing standard requirements |
| Collection Device | Recovers fallen abrasives and wear particles |
Testing Principle
During testing, standardized abrasives fall freely through the conduit under gravity from a specified height, continuously impacting the sample surface. As the test progresses, the coating gradually wears. By measuring the coating thickness or wear per unit area before and after the test, you can evaluate the coating’s abrasion resistance. This method effectively simulates particle-induced wear in real-life use.
