Expansion Tank Static Pressure Test Machine

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The Expansion Tank Static Pressure Test Machine is suitable for a variety of automotive component testing applications:

Expansion Tanks: Evaluate static pressure resistance, leakage, and functional performance.

Coolant System Components: Test caps, valves, and connectors under controlled static pressure.

Material Durability Testing: Assess long-term reliability of plastic, metal, and composite tank materials.

Quality Control: Ensure compliance with OEM and supplier specifications for automotive cooling systems.

R&D and Certification Testing: Support component development, validation, and system integration.

Typical test products include automotive expansion tanks, coolant reservoir tanks, and associated components requiring static pressure evaluation.

Standards

The system supports compliance with major automotive engineering standards:

VW TL889 (4.1) – Volkswagen Group technical specification for interior and related component functional performance.

ESDG93-8A080-AA (3.6) – Ford engineering specification for component functionality and reliability.

GMW15310 (3.2.1.2) – General Motors global standard for material and component performance testing.

QV17004D (3.2.6) – BMW group specification for system component functionality and durability.

Parameters

Parameter CategoryDetails
Test Bench Dimensions 2200 × 2240 × 1550 mm (W × H × D)
Chamber Dimensions 1000 × 800 × 1000 mm (W × H × D)
Rated Power 9.5 kW
Test Medium Glycol/Water
Pressure Range 0 … 5 bar
Flow Rate per Sample 0 … 8 l/h
Pressure Type Static
Test Medium Temperature Range 25 … +150°C
Environmental Temperature Range 25 … +150°C
Test Channels 6

Features

Designed specifically for static pressure testing of expansion tanks.

Static pressure adjustable from 0 up to 5 bar.

Individual sample flow rate controllable from 0 to 8 l/h.

Explosion protection level 1 due to indirect chamber heating.

Automatic leak detection and leak testing with fail-safe shutdown of defective samples.

Automatic control of liquid level during testing.
