Automotive Wire Scratch Resistance Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Automotive Wire Scratch Resistance Tester is designed to evaluate the abrasion resistance and durability of automotive wire insulation under mechanical wear conditions. You can use this device to simulate long-term friction, vibration, and contact stress, ensuring that wire coatings maintain integrity and prevent conductor exposure during service life.
Application
This tester is suitable for:
(1) Abrasion resistance testing of automotive wires and cables.
(2) Evaluation of insulation durability in wire harness systems.
(3) Quality control of cable coatings and insulation materials.
(4) R&D validation of wiring systems for automotive, aerospace, and electronics applications.
Standards
The tester adheres to global standards for material abrasion testing, including:
ISO 6722-1(Road vehicles – Electrical cables – Test methods for abrasion resistance)
SAE J2394(Standard test for electrical resistance of automotive wire insulation under abrasion)
LV 112(Volkswagen standard for automotive cable durability)
GB/T 5023(China’s national standard for electric cables – Abrasion tests)
UL 758(Appliance Wiring Material standard for insulation integrity)
Main Parameters
| Parameter | Specification |
|---|---|
| Load Range | 1–50 N (adjustable for light to heavy abrasion) |
| Abrasion Head | Tungsten carbide tip (1 mm diameter) or steel wool (customizable) |
| Stroke Length | 10–100 mm (programmable) |
| Test Speed | 10–60 cycles/min (adjustable) |
| Sample Dimensions | Up to 5 meters (cable length); 1–10 mm diameter |
| Control System | PLC-based with 7-inch touchscreen (multilingual interface) |
| Power Supply | 220V/50Hz, 200W |
| Dimensions | 600 × 450 × 1200 mm (L × W × H) |
