Luggage lifting and unloading testing machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The luggage simulation lifting and unloading tester is a measuring instrument for the life of the handle of the luggage carrier. It is one of the important equipment for testing the performance and quality of luggage products. Product data can be used as a standard reference for judging the performance of luggage and can be used as an important basis for buyers to select bags.
Application
1.Handle strength test: Simulates repetitive impact under carrying conditions to detect the risk of stitching failure.
2.Overall structure test: Verifies the deformation of the case frame through cyclic testing to optimize material selection and structural design.
3.Component durability test: Evaluates the reliability of key components such as the pull rod and wheels during long-term use.
Standards
QB/T 1586.3：Hardware fitting of case and bag - Case-handle
Features
Made of high-quality cold-rolled steel plate with high-temperature baking paint treatment, it is aesthetically pleasing and easy to clean and maintain.
It uses a variable frequency motor drive, ensuring stable running speed, low noise, and high stability.
The sample fixture is made of imported aluminum profiles, which are lightweight, have a smooth surface, and are rust-proof.
The equipment features an imported silk-screened panel with silicone buttons, providing sensitive operation and durability.
It uses a color touchscreen for operation and display.
Technical Parameters
| Technical Parameter | Specification |
|---|---|
| Lifting height | 0-300mm adjustable, eccentric drive convenient stroke adjustment |
| Amplitude | 0——10cm adjustable |
| Speed | 0-30 times adjustable |
| Test weights | 5kg, 10kg each |
| Counting quantity | Display 0——999999 times (can be set counting stop) |
| Transmission motor | Variable frequency motor |
| Power supply | 1 #, 220V/50HZ |
| Machine volume | 150014001800mm |
| Machine weight | About 120kg |
