High Precision 4-Station Abrasion Resistance Test Equipment

Get a quote：

Whats/App: +86 156 1874 6768

Web: standard-groups.com

The Nissan 4-Station Abrasion Tester is a high-efficiency laboratory instrument designed for evaluating the abrasion resistance of textiles, leather, coated fabrics, plastics, and rubber materials. This multi-station abrasion tester allows simultaneous testing of four independent samples, significantly reducing testing time while maintaining precision and repeatability.

Application

(1) Testing abrasion resistance of textiles, including apparel, upholstery, and automotive fabrics

(2) Evaluating wear durability of leather goods, such as shoes, bags, and furniture

(3) Assessing coated fabrics, rubber, and plastics for industrial or automotive components

(4) Quality control in manufacturing and R&D laboratories

(5) Comparative material performance testing under rotary or reciprocating abrasion

Standard

ASTM D3884(Standard Guide for Abrasion Resistance of Textile Fabrics)

ISO 5470-1(Rubber- or Plastics-Coated Fabrics - Abrasion Resistance)

TABER Abrasion Test Methods(Adapted for multi-station parallel testing)

Features

(1) Independent 4-station design reduces testing time by up to 75%

(2) Variable pressure and speed control to simulate light to heavy abrasion

(3) Supports rotary and reciprocating abrasion modes for different sample geometries

(4) Real-time wear monitoring with high-resolution cameras and AI fuzz/pill detection

(5) Cloud-compatible data management with ISO/ASTM/TABER® compliant reporting

(6) Modular abrasive heads for flexible material testing

(7) Safety features including overload protection, emergency stop, and CE/UL compliance

Technical Parameters

Parameter	Specification
Number of Stations	4 (independent control)
Pressure Range	0.5–5 N (±0.01 N accuracy)
Speed Range	20–200 RPM (±1 RPM accuracy)
Stroke Length	10–50 mm (±0.1 mm resolution)
Dimensions (L×W×H)	1.200×800×1.500 mm
Weight	280 kg
Operating Environment	15–35°C, ≤85% RH (non-condensing)
Power Supply	220V/110V AC, 50/60Hz, 2.5kW

Accessories

Abrasive Heads: 4× standard felt discs (dry/wet compatible).

Calibration Kit: Pressure gauge, speedometer, and NIST-traceable certification.

Sample Clamps: 8× quick-release holders for flat/curved materials.

User Manual: Multilingual guide (English, Spanish, German, Chinese) with maintenance tips.

Dust Collection System: HEPA-filtered vacuum for clean operation.

Ideal For:

Textile manufacturers (apparel, upholstery, automotive interiors)

Leather goods producers (shoes, bags, furniture)

Plastic/rubber component suppliers (automotive, electronics)

Third-party labs (ISO/ASTM/TABER® certification)
