DIN 5510 Fourier Infrared Smoke Toxicity Analysis System
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The FTIR Fourier Transform Infrared Smoke Toxicity Test System is an integrated gas analysis solution designed for real-time and quantitative measurement of toxic gas components in smoke. The system is equipped with a multi-pass gas cell featuring a 5-meter optical path and is fully integrated into a 19-inch standard industrial chassis. Based on Fourier Transform Infrared (FTIR) spectroscopy, the system enables stable, durable, and long-term operation for automatic gas monitoring and analysis. With high-reliability core components such as the interferometer, infrared light source, and diode laser, the system significantly enhances operational stability while reducing overall maintenance and operating costs, making it suitable for smoke toxicity testing and industrial gas analysis applications.
Standards
The system supports smoke toxicity testing and gas analysis in accordance with the following international and industry standards:
(1) DIN 5510-2 – Fire Behaviour and Smoke Toxicity of Materials Used in Railway Vehicles
(2) ISO 19702 – Guidelines for Sampling and Analysis of Toxic Gases and Vapours in Fire Effluents Using Fourier Transform Infrared (FTIR) Spectroscopy
(3) ISO 5659-2 – Plastics — Smoke Generation — Part 2: Determination of Optical Density by a Single-Chamber Test
(4) EN 45545-2 – Railway Applications — Fire Protection on Railway Vehicles — Requirements for Fire Behaviour of Materials and Components
Parameters
| Item | Specification |
|---|---|
| Quantifiable Gas Species | More than 300 compounds |
| Spectral Range | 4500–800 cm⁻¹ |
| Spectral Resolution | Better than 1 cm⁻¹ |
| Gas Analysis System | Multi-pass gas cell with 5 m optical path |
| Working Pressure | 0–15 bar |
| Maximum Working Temperature | Up to 191 °C |
| Dedicated Filter | Filters dust particles ≥ 2 μm |
| System Integration | 19-inch standard industrial chassis |
Features
Wide application flexibility, enabling gas measurements under different pressure and temperature conditions through appropriate accessories.
Optimized high-throughput optical design of the gas cell allows quantitative analysis of mixed gases even at concentrations as low as the ppb level.
No gas calibration is required; the system software automatically retrieves target gas concentrations using nonlinear fitting algorithms.
Effects caused by interfering gases and temperature variations are automatically compensated, ensuring accurate real-time qualitative and quantitative results.
Optical system employs a thermoelectrically cooled detector, CenterGlow™ infrared light source for stable high emission, and a RockSolid interferometer to ensure permanent optical alignment.
Equipped with dedicated sampling probes for gas extraction from pipelines or sealed chambers.
Independent and complete gas analysis software package with an intuitive graphical user interface.
Enables fast, continuous, and fully automated gas identification and quantification without requiring specialized user expertise.
