Transmission belt flammability and flame diffusion characteristics tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Transmission Belt Flammability and Flame Diffusion Characteristics Tester is designed to evaluate the flammability and flame propagation behavior of conveyor belts, including textile body belts, steel cord belts, and horizontally oriented belts. The instrument provides controlled ignition and combustion monitoring to ensure compliance with international safety standards.
Application
(1) Flammability testing of textile and steel cord conveyor belts
(2) Evaluation of flame propagation speed and characteristics
(3) Safety assessment for mining, industrial, and transportation conveyor systems
(4) Quality control and R&D for conveyor belt manufacturers
(5) Laboratory testing in compliance with ISO and AS standards
Standards
AS 1334.10-1994 – Determination of flammability and flame propagation characteristics of conveyor belts
ISO 340-2022 – Conveyor belts: Flammability characteristics at laboratory scale; requirements and test methods
Parameters
| Parameter | Specification |
|---|---|
| Ignition Time Setting Range | 0 – 999.9 s |
| Combustion Timing Range | 0 – 999.9 s |
| Bunsen Burner Inner Diameter | 10.5 mm |
| Bunsen Burner Rotation Angle | 0° – 45°, adjustable |
| Thermocouple Type | K-type armored |
| Thermocouple Display Range | 0 – 1300℃ |
| Test Flame Temperature | 1000 ± 20℃ |
| Flame Scale | 50 – 150/180 mm |
| Combustion Chamber Size | 500 × 500 × 500 mm |
| Combustion Gas | Propane gas, purity > 95% |
| Instrument Dimensions | 555 × 651 × 738 mm |
| Weight | ≈ 80 kg |
| Power Supply | AC 220V ± 10%, 50 – 60 Hz |
