OEM Female Side Impact Dummy Manufacturer
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The 5th Percentile Female Side Impact Dummy is a next-generation biomechanical surrogate designed based on anthropometric data of small adult females (5th percentile). You can use it to simulate real female occupants’ biomechanical responses during vehicle side collisions. The dummy is optimized for side impact protection systems, enabling systematic evaluation of side airbags and lateral vehicle structures on occupant safety.
Standards
This dummy complies with the following national and international standards:
(1) GB 20071 – Protection of occupants in side collisions
(2) GB/T 29120 – Anthropomorphic test device general technical requirements
(3) GB/T 24550 – Vehicle collision test methods
(4) ISO 6487 – Road vehicles — Measurement techniques in impact tests
(5) SAE J211 – Instrumentation for impact tests
(6) UN R95 – Side impact occupant protection
(7) FMVSS 214 – Side impact protection
(8) Euro NCAP – Side impact test protocols
(9) C-NCAP – Side impact test protocols
(10) US NCAP / IIHS – Side impact test protocols
(11) J-NCAP / K-NCAP / ASEAN NCAP / ANCAP – Side impact test protocols
Parameters
Dimensions
| No. | Name | Dimension (mm) |
|---|---|---|
| A | Seated Height | 780 ±8 |
| B | Shoulder Pivot to Seat Plane | 445 ±8 |
| C | H-Point to Seat Plane | 84 ±5 |
| D | H-Point to Backplane | 146 ±5 |
| E | Shoulder Pivot to Backplane | 102 ±5 |
| F | Thigh Thickness | 127 ±8 |
| G | Head Width | 144 ±4 |
| H | Head Rear to Backplane | 43 ±3 |
| I | Head Depth | 183 ±5 |
| J | Head Circumference | 546 ±5 |
| K | Hip to Knee Front | 527 ±13 |
| L | Foot to Seat Plane | 356 ±13 |
| M | Foot to Knee Pivot | 401 ±8 |
| N | Hip to Popliteal Distance | 429 ±13 |
| O | Chest Thickness (No Clothing) | 203 ±8 |
| P | Foot Length | 224 ±8 |
| Q | Hip Width | 318 ±5 |
| R | Arm Length | 254 ±5 |
| S | Knee Pivot to Backplane | 485 ±8 |
| V | Shoulder Width (Single Arm) | 349 ±8 |
| W | Foot Width | 86 ±8 |
| Y | Chest Circumference (Clothed) | 866 ±15 |
| Z | Waist Circumference | 776 ±15 |
Mass Distribution
| Component | Mass (kg) |
|---|---|
| Head Assembly | 3.70 ±0.05 |
| Neck Assembly | 0.91 ±0.09 |
| Upper Torso (No Clothing) | 11.11 ±0.20 |
| Lower Torso | 12.52 ±0.18 |
| Arm Assembly (Single Side) | 0.91 ±0.05 |
| Thigh (L/R) | 3.13 ±0.09 |
| Lower Leg (L/R) | 3.27 ±0.09 |
| Foot (L/R) | 0.79 ±0.05 |
| Clothing | 0.59 ±0.07 |
| Total Dummy Weight | 44.12 ±1.09 |
Features
(1) Based on 5th percentile adult female anthropometric data, representing small-stature female occupants
(2) Optimized for side impact scenarios, suitable for lateral injury assessment
(3) Supports 100+ data channels, covering head, chest, abdomen, pelvis, and lower limbs
(4) Modular structure, each body segment corresponds anatomically
(5) Material combinations simulate human bones, soft tissues, and muscle response characteristics
(6) Highly compatible with mainstream regulatory and NCAP side impact test protocols
