ASTM G99 Block-on-Ring Tribometer Manufacturer
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Ring-on-Block Friction and Wear Tester (Type 1) is designed to evaluate the wear resistance of metals, non-metallic materials (such as nylon, plastics), and coated surfaces under sliding friction conditions. You can simulate different working environments, including dry and lubricated friction, to study material wear behavior. The device features a color touchscreen for real-time display of test parameters and data curves, facilitating detailed analysis.
Standards
GB 3960-2016 – Test Method for Sliding Friction and Wear of Plastics
ASTM G99 – Standard Test Method for Wear Testing with a Pin-on-Disk Apparatus
ASTM G133 – Standard Test Method for Linearly Reciprocating Ball-on-Flat Sliding Wear
ISO 7148-2 – Tribology – Testing of Unlubricated Metal/Metal Sliding Contacts – Part 2: Block-on-Ring and Pin-on-Disc Methods
ISO 20808 – Metallic Materials – Test Method for Sliding Wear
DIN 50324-1 – Tribology – Testing of Friction and Wear – Pin/Disc Method
DIN 50324-2 – Tribology – Testing of Friction and Wear – Block/Ring Method
ASTM D1894 – Standard Test Method for Static and Kinetic Coefficients of Friction of Plastic Film and Sheeting
ASTM D3702 – Standard Test Method for Wear Testing of Plastics with a Pin-on-Disk Apparatus
ISO 4649 – Rubber, Vulcanized or Thermoplastic – Determination of Abrasion Resistance Using a Rotating Cylindrical Drum Device
ASTM F732 – Standard Test Method for Wear Testing of Polymer and Composite Materials
Technical Specifications
| Parameter | Specification |
|---|---|
| Test Force Range | 10 – 1000 N |
| Maximum Friction Torque | 4000 N·mm |
| Spindle Speed Range | 100 – 1000 r/min |
| Test Duration Display & Control | 1 – 99999 s or min |
| Revolutions Display & Control | 0 – 999.999.999 |
| Rated Power | 1.1 kW |
| Dimensions (L × W × H) | Approx. 860 × 400 × 660 mm |
Features
Multi-Functional Testing: Evaluate metals, non-metals, and coated materials under different friction conditions
Adjustable Parameters: Test force, spindle speed, and friction torque are configurable to meet different experimental needs
Real-Time Data Monitoring: Color touchscreen displays and records test data continuously
Data Visualization: Test curves are plotted in real time, clearly showing the wear process
High Reliability: Compact, stable design suitable for laboratory and industrial use
Accessories
| Name | Description |
|---|---|
| Friction Pair Materials | Materials for metals, non-metals, and coatings |
| Test Force Sensor | For precise control of applied force |
| Temperature Sensor | Monitors sample temperature during testing |
