Advanced Multi-Axis Tribometer for Tribology Laboratory
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Multi-Axis Tribometer is a versatile tribological testing device for studying friction and wear of materials under low to medium load conditions. It supports multiple contact configurations including pin- or ball-on-rotating-disc and pin- or ball-on-plate reciprocating tests. With a lateral indexing function, the device allows continuous exposure of fresh wear surfaces, making it suitable for fundamental tribology research and various standardized test methods.
Standards
You can perform tests in accordance with:
ASTM G119 – Guide for Wear Testing.
ASTM G99 – Pin/ball-on-disc friction and wear test.
ASTM G132 – Pin-on-disc wear test with indexing function.
DIN 50324 – Pin-on-disc friction and wear testing.
Parameters
Base Unit
| Parameter | Specification |
|---|---|
| Contact Configuration | Ball-on-flat / Pin-on-flat / Custom samples |
| Normal Load Range | 0.1 – 100 N |
| Load Measurement | Strain gauge force sensor |
| Friction Force Range | 0 – 50 N |
| Friction Measurement | Strain gauge force sensor |
| Humidity Measurement | 10 – 90 % RH |
| Drive Motor | Brushless DC servo, 200 W |
| Loading Actuator | Linear actuator, 12 V DC, 100 N |
| Indexing Actuator | Linear actuator, 12 V DC, 100 N |
| Interface | USB serial interface |
| Control Software | Proprietary control software |
| Installation | Benchtop |
| Protection | Transparent safety shield |
P-Indexed Pin-on-Disc Module
| Parameter | Specification |
|---|---|
| Contact Configuration | Ball-on-disc / Pin-on-disc |
| Disc Diameter | 100 mm |
| Track Radius | 0 – 40 mm |
| Lateral Feed Speed | 10 mm/min |
| Disc Speed | 0 – 300 rpm |
| Maximum Sliding Velocity | 1 m/s |
R-Indexed Reciprocating Module
| Parameter | Specification |
|---|---|
| Contact Configuration | Ball-on-plate / Plate-on-plate / Plate-on-hemisphere |
| Max Reciprocating Velocity | 10 mm/s |
| Max Stroke | 50 mm |
| Max Lateral Velocity | 1 mm/s |
| Max Lateral Travel | 30 mm |
| Temperature Range | Ambient – 100°C |
| Dwell Time | 0 – 8 hours |
| Temperature Sensor | Type J thermocouple |
| Heating Power | 150 W |
H High-Temperature Non-Indexed Pin-on-Disc Module
| Parameter | Specification |
|---|---|
| Disc Diameter | 75 mm |
| Track Radius | 0 – 35 mm |
| Temperature Range | Ambient – 500°C |
R/C Cooling Module
| Parameter | Specification |
|---|---|
| Minimum Temperature | −15°C (ambient water cooling) |
| Minimum Temperature | −30°C (chiller water/ethylene glycol) |
Features
(1) Multi-axis, multi-module configuration covers both rotational and reciprocating tests.
(2) Indexing function allows continuous exposure of fresh wear surfaces, meeting ASTM G132 requirements.
(3) Electric loading system supports pre-test dwell time settings.
(4) Force-decoupled structure measures only tangential friction force, avoiding normal load interference.
(5) Stable friction measurements for elastomers and large-deformation samples.
(6) Modular design allows quick change of test configurations.
(7) Supports temperature and humidity monitoring and controlled environmental tests.
(8) Automatic data recording with export in .csv or .tsv format.
Accessories
(1) /P Indexed Pin-on-Disc Module
(2) /R Indexed Reciprocating Module
(3) /H High-Temperature Pin-on-Disc Module
(4) /R/S Stick-Slip Test Adapter
(5) /R/R Rubber Friction Test Fixture
(6) /R/C Cooling Module
(7) Test samples – Pin / Ball (user-supplied)
(8) Test samples – Disc / Plate (user-supplied)
