Model Coin-cell Swelling System for Lithium-ion Battery Research
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
(1) ASTM E83 – Standard Test Method for Verification of Linear Displacement Measuring Systems.
(2) ISO 12417-1 – Mechanical Testing of Metals – Dilation Test (reference method).
(3) IEC 62660-2 – Secondary Lithium-Ion Cells – Reliability and Abuse Testing.
(4) DIN 51221 – Testing of Adhesives – Determination of Tensile Shear Strength (reference for deformation testing).
(5) CE Certification – Conformité Européenne.
Features
(1) Micron-level non-contact laser displacement measurement with high repeatability.
(2) High-resolution detection of subtle thickness and volume changes in coin cells.
(3) Multi-environment testing capability with integrated temperature chamber.
(4) Dynamic pressure loading for electrode stack fatigue and structural response analysis.
(5) Eight-channel parallel testing to improve screening efficiency and data consistency.
(6) Laser-guided positioning system for precise coin-cell alignment.
(7) Automatic thermal drift compensation during long-term cycling tests.
(8) Dual redundant safety protection with emergency stop function.
(9) Glovebox-compatible design for oxygen- and moisture-sensitive chemistries.
Parameters
| Parameter | Specification |
|---|---|
| Displacement Range | ±500 μm (linear), ±0.5° (angular) |
| Linear Measurement Accuracy | ±0.05 μm |
| Angular Measurement Accuracy | ±0.005° |
| Displacement Resolution | 0.1 μm |
| Temperature Range | -20°C to 150°C |
| Temperature Ramp Rate | ≤ 2°C/min |
| Pressure Range | 0–10 bar |
| Test Channels | 8 channels |
| Data Acquisition Rate | 10.000 points/s/channel |
| Power Supply | AC 100–240 V, 50/60 Hz |
| Dimensions (W×D×H) | 400 × 350 × 600 mm |
| Weight | 65 kg (net) / 80 kg (gross) |
Accessories
(1) Non-magnetic coin-cell holders for 2032. 2025. and 2016 formats.
(2) Laser displacement sensor modules.
(3) Temperature-controlled environmental chamber.
(4) Pressure loading and control unit.
(5) Data acquisition and analysis software.
(6) NIST-traceable displacement calibration standards (100 μm, 500 μm).
(7) Gas purification cartridge for inert atmosphere operation.
(8) Humidity sensor with data logging function.
