OEM Camera Airtightness Testing Machine
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
(1) IEC 60529 (IP Code protection classification)
(2) ISO 20653 (Road vehicles – degrees of protection)
(3) GB/T 4208 (Enclosure protection standard)
(4) GB/T 2423.23 (Environmental sealing test methods)
(5) MIL-STD-810 (Environmental engineering considerations for military equipment)
Parameters
| Item | Specification |
|---|---|
| Test Pressure Range | 90–450 kPa |
| Leakage Resolution | 0.1 Pa |
| Pressure Accuracy | ±0.25% F.S |
| Allowable Leakage | -0.1 to 0.1 kPa |
| Test Cycle Time | 5–15 s per stage |
| Test Method | Differential pressure / Direct pressure |
| Control System | PLC automatic control |
| Data Output | USB / RS485 / Ethernet |
Features
(1) High-precision differential pressure detection for micro-leakage identification
(2) Supports both direct pressure and differential pressure testing modes
(3) Fast testing cycle suitable for mass production environments
(4) Automatic OK/NG judgment with real-time output
(5) Data storage and traceability for quality management systems
(6) Stable mechanical structure suitable for continuous operation
Accessories
(1) Dedicated sealing fixture for camera modules
(2) High-precision pressure sensor module
(3) Air supply regulation and filtration system
(4) PLC control system
(5) Standard calibration leak reference unit
