Automatic Floor Scrubber Suction Performance Test System Factory Supplier
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
IEC 60312:2010 – Rotodynamic Vacuum Cleaners – Methods for Measuring the Performance
F431-21 – American Standard for Vacuum Cleaner Performance Testing (Airflow, Suction, and Power)
F558-17 – American Standard for Vacuum Cleaner Energy Efficiency and Flow Measurement
GB/T 20291.1-2014 – Performance Test Methods for Vacuum Cleaners
ISO 29463-3:2011 – HEPA and ULPA Filters for Airborne Particle Removal
Features
Supportsboth European and American testing standards
Real-time monitoring ofvoltage, current, power, suction, and airflow
High accuracy withservo-driven flow measurement and vacuum detection
Automatic data acquisition, calculation, andUSB export or print output
Single-station design allowsefficient space utilization
Suitable for testingfloor scrubbers and hybrid vacuum-cleaner units
Technical Parameters
| Item | Specification |
|---|---|
| Test Stations | Single station |
| Pressure Chamber Dimensions | Euro standard: 500×500×500 mm; US standard: 457.2×457.2×254 mm |
| Test Modes | Euro standard, US standard |
| Drive Motor | Servo motor |
| Flow Meter | Range: 0.5–5 m³/min; Accuracy: ±1% |
| Vacuum Gauge | Range: -50–0 Kpa; Accuracy: ±1% |
| Orifice Plate Sizes (US & Euro standard) | 63.5. 57.2. 50.8. 44.5. 38.1. 34.9. 31.7. 28.6. 25.4. 22.2. 19.0. 15.8. 12.7. 9.5. 6.3 mm |
| Power Supply & Current Detection | AC: 0–250V; DC: 0–60V; Current detection range: 0–30A |
| Equipment Power | 220V, 2.5KW |
| Equipment Dimensions | 1850×1150×1750 mm |
Accessoriess
(1) Servo-driven motor control system
(2) Industrial control computer with 17-inch touchscreen display
(3) European standard equalizing chamber
(4) American standard equalizing chamber with rotary orifice plate set
(5) Flow meter and vacuum pressure sensors
(6) Data export interface (USB)
