Drying Rate Tester Heated Plate Method ISO Standard Manufacturer
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
AATCC 201-2013 Fabric Drying Rate: Hot Plate Method
FZ/T 01176-2024 Textiles - Determination of Fabric Drying Rate - Hot Plate Method
Features
1. Incorporates high-precision wind speed sensors, infrared temperature sensors, temperature sensors, precision dripping devices, high-accuracy wind speed control units, and fluid dynamics-optimized air ducts.
2. Integrates with computer software to automatically perform fabric drying time and drying rate tests along with comprehensive data analysis, significantly enhancing operational efficiency and measurement accuracy while minimizing human-induced errors.
3. Test software communicates with the main unit via USB port, displaying and saving data as curves and charts for easy analysis and printing. Wide adjustable ranges for wind speed (0.2–4.5 m/sec) and drip volume (0.05–4.5 ml).
4. The hot plate method not only complies with the AATCC 201 testing standard but is also suitable for knitted fabrics or any quick-drying fabrics (excluding fabrics used in socks).
Parameters
| Item | Specifications |
|---|---|
| Air Chamber | Capable of generating 0.2–3 m/sec airflow |
| Heating Plate | 300mm×300mm±1mm |
| Flexible Heating Sheet | 300mm×300mm±1mm |
| Insulation Soft Board | 300mm×300mm±1mm |
| Heating Plate Temperature | 37±0.5°C (with overheat protection) |
| Air Velocity | 0–2.5 m/s±0.1 m/s |
| Infrared Temperature Sensor | 15–50°C±0.1°C |
| Data Transmission | USB data transmission |
| Test Interface | Curves and charts displayed simultaneously |
| Test Report | Automatically saved, easy to print |
| Power Supply | AC 230V, 50Hz/60Hz |
| Overall Dimensions (L×W×H) | 450×320×170 mm |
| Weight | Approximately 45 kg |
