Pendulum Impact Tester manufacturer direct factory price China supplier
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
ASTM D 256-2010、ASTM D6110-2004、
ISO 180:2000、ISO 179-1:2010、ISO 13802:99;
JIS K 7110:1999、JIS K 7111: 1996、JB/T 8761-1998
DIN 53453
GB/T 21189-2007、GB/T 1843-2008、GB/T 1043.1-2008、GB/T 1697-2001、GB/T 1451-2005、GB/T 18743-2002;
Principle
The Pendulum impact tester is specifically designed to determine the impact resistance of various plastic materials under specific conditions of angle and energy. Equipped with a high-precision encoder and advanced operating system, this instrument conducts impact tests rapidly and calculates the impact energy accurately.
Wide applicability:
Well-suited to assess the impact resistance across various industries, including material science, industrial manufacturing, construction, aviation, and automotive.
Multiple testing methods:
Supports both Charpy and Izod test modes, as well as a variety of unit options, enabling operators to meet various testing requirements.
High precision testing:
With its advanced detection system, the Pendulum impact tester ensures accurate test results, offering reliable insights into how materials behave under impact.
Digital operation:
Featuring an intuitive interface for monitoring and operating tests, the Pendulum impact tester minimizes the risk of errors during operation.
Standard conformity:
Designed in accordance with international standards, the Pendulum impact tester ensures the reliability and comparability of test results.
Parameter
1. Capacity
Ø Charpy for plastics: 1J, 2J, 4J, 7.5J, 15J, 25J, 50J
Ø Charpy for plastic pipe: 15J, 50J
Ø Izod: 2.75J, 5.5J, 11J, 22J
Ø Tensile impact: 7.5J, 15J, 25J
2. Angle of striking: 150°
3. Angle resolution: 0.045°
4. Charpy Test for plastics (ISO 179)
Ø Velocity of striking: 2.9m/s (≤5J), 3.8m/s (>5J)
Ø Distance from the axis of support to the center of percussion: 230mm(≤5J), 395mm(>5J)
Ø Span: 40mm, 60mm, 70mm (can be adjusted by span block)
Ø Specimen dimension (LxWxH):
80mmx10mmx4mm, 50mmx6mmx4mm, 120mmx15mmx10mm
5. Charpy Test for plastic pipe (ISO 9854.1)
Ø Velocity of striking: 3.8m/
Ø Distance from the axis of support to the center of percussion: 395mm
Ø Span: 40mm, 70mm (can be adjusted by span block)
6. Izod test (ISO 180. ASTM D256)
Ø Velocity of striking: 3.5m/s
Ø Distance from the axis of support to the center of percussion: 335mm
Ø Striking knife center to vice upper surface: 22±0.2mm
Ø Specimen dimension (LxWxH): 80x10x4mm, 63.5x12.7x12.7mm
63.5x12.7x6.4mm, 63.5x12.7x3.2mm
7. Tensile impact test (ASTM D1822. ISO 8256)
Ø Velocity of striking: 3.444m/s
Ø Distance from the axis of support to the center of percussion: 327mm
Ø Pendulum initial elevation height: 610mm
Ø Crosshead mass: 60±1g, 120±1g
Ø Maximum specimen thickness: 4mm
8. Power supply: AC220V, 50Hz, 0.3kW
9. Machine dimension (LxWxH): 1000x300x760mm
10. Weight: 255kg
