Feature
Microprocessor control, vertical combustion, can also do horizontal combustion, automatic ignition, digital display, automatic control, can set the combustion length, automatic smoke exhaust function
Parameters
| Description | Details |
|---|---|
| Smoldering distance | 20——180mm, set at will |
| Distance accuracy | ±0.1mm |
| Time accuracy | 0.1 seconds |
Accessoriess
Combustion chamber, ignition device, sample holder, temperature sensor, timer, data recording and display device, exhaust system, etc.
Test Procedures
Power-on self-test: Turn on the power switch. The instrument will perform a self-test. After the LCD displays the relevant information, it will enter standby mode. At this time, the yellow LED on the control panel will light up.
Sample installation: Open the cover, horizontally push the sample into the end of the test slot and straighten it. After 3 seconds, the clamping device will automatically clamp the sample. Close the cover.
Start testing: Press the [Start] button. The instrument will automatically ignite the sample. After the paper disc is ignited, it will burn automatically. When the burning reaches the first photoelectric receiving point, the system will indicate that the test has started and begin timing.
Observation and recording: The support rod will descend with the progress of the burning. When the burning reaches the last photoelectric receiving point, the system timing ends, and the test results are displayed on the screen.
Subsequent processing: After a few seconds, the exhaust fan will operate to remove the smoke. After the test is completed, remove the ash tray for cleaning. You can press the [A] button to display the results, press the [Print] button to print, and you can also query the results using key combinations.
