Standard Helmet Visual Field Tester
Standard
- EN 1078:2023: Helmets for Pedal Cyclists, Skateboarders, and Roller Skaters
- CE Certification(Conformité Européenne)
- Equivalent Compliance: ASTM F1446 (Respiratory Protective Devices)
Product Advantages
- EN 1078:2023 Compliance
- 25°+ Upper / 45°+ Lower / 105°+ Lateral Vision: Ensures helmets meet minimum peripheral visibility requirements.
- ±0.5° Angular Accuracy: Validates visor designs for road/urban safety certifications.
- Precision Engineering
- 360° Rotational Stage: Tests visor obstructions from all riding positions.
- Auto-Leveling System: Compensates for helmet tilt during dynamic testing.
- User-Centric Design
- 7” Touchscreen HMI: Preloaded EN 1078 test sequences with pass/fail indicators.
- Quick-Release Visor Clamp: Swaps samples in seconds for high-volume labs.
- Data Integrity
- Built-In Data Logger: Exports test results as PDF/CSV for audit trails.
- SD Card Storage: 16GB capacity for years of test archives.
- Durability
- Aircraft-Grade Aluminum Frame: Resists deformation during 5,000+ test cycles.
- Anti-Scratch Visor Coating: Protects optics from helmet abrasion.
Product Features
- Motorized Goniometer: 0.01° resolution for precise angular measurements.
- Modular Head Assembly: Fits adult, child, and custom helmet sizes (50–65 cm circumference).
- Dynamic Obstruction Detection: Lasers map visor blind spots in real-time.
- Self-Calibrating System: Auto-tare and angular alignment checks before each test.
- Rust-Resistant Frame: 304 stainless steel construction with epoxy coating.
Technical Parameters
| Parameter | Specification |
|---|---|
| Field of View | Upper ≥25°, Lower ≥45°, Lateral ≥105° |
| Angular Accuracy | ±0.5° (ISO 17025 traceable) |
| Measurement Range | 0–360° (horizontal/vertical) |
| Head Model | Quick-swap anthropomorphic mandible |
| Power Supply | 220V AC, 50/60Hz (single-phase) |
| Dimensions | 800mm (W) × 600mm (D) × 1,500mm (H) |
| Weight | 120 kg (net) |
Accessories Included
- Testing Kit:
- 2x Adult-Size Head Forms (56cm/58cm circumference).
- 5x Calibration Grade Angular Encoders.
- Software Suite:
- License key forVisorTest Pro(Windows/macOS).
- 1-year free access to cloud-based vision analysis tools.
- Calibration & Safety:
- NIST-traceable inclinometer.
- 2x Safety Glasses (EN 166 rated).
- Maintenance Kit:
- Spare drive belts and bearings.
- Machine cleaning solution (non-corrosive).
- Documentation:
- Multilingual quick-start guide (printed + digital).
- Compliance certificates for EN/ISO standards.
Send product request
