Thermal Abuse Chamber
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1.Absolute safety in extreme environments
The robust explosion-proof/pressure-resistant structure, integrated pressure relief device and gas emission treatment system can safely accommodate the intense phenomena caused by battery thermal runaway.
2.Comprehensive coverage of extreme testing capabilities
Wide temperature range: temperature range of -70°C to +170°C, covering the entire environmental stress of the battery throughout its life cycle.
Fast temperature change: A temperature change rate of 10°C/min (average), efficiently triggering thermal runaway.
3.Complies with mandatory compliance certifications
Complies with strict international battery safety standards (such as UN 38.3. IEC 62619), which are indispensable certification tools for power batteries and energy storage batteries entering the market.
4.Extremely large test volume and flexible adaptation
1000L internal space, capable of accommodating large power battery modules, energy storage units, or batches of single batteries;Compatible with thermal diffusion test requirements for modules/battery packs.
Specifications
|
Model |
STD TR10-1000C |
|
|
Internal Dimension (mm)
|
1000*1000*1000 |
|
|
Overall Dimension (mm)
|
2120*1200*2100 |
|
|
Interior Volume |
1000L |
|
|
Parameters |
Temperature Range |
C : -70℃～+170℃ |
|
Temperature Fluctuation |
±0.5℃ |
|
|
Temperature Deviation |
±2.0℃ |
|
|
Cooling Rate |
10 ℃/ min（average） |
|
|
Heating Rate |
10 ℃/ min（average） |
|
