Plastic Pipe Hydrostatic Pressure Burst Tester / Pipe Hydrostatic Pressure And Burst Tester
Standard
ISO 1167: For thermoplastics pipe systems under constant internal pressure.
ASTM D 1598: Standard test method for time-to-failure of plastic pipe under constant internal pressure.
ASTM D 1599: Standard test method for resistance to short-time hydraulic pressure of plastic pipe.
ASTM F1335
ISO9080
CJ/T108
Product Advantages
1. High Precision & Quality
Industry-Leading Microprocessor Controller: Achieve ultra-precise pressure regulation (±0.1% FS) with real-time TCP/IP data exchange for seamless integration with lab networks.
Advanced Calibration: Optional auto/manual pressure sensor calibration before or during tests ensures traceable accuracy.
2. Modular Flexibility
Scalable Design: Expand testing capabilities effortlessly with modular stations—adapt to diverse pipe materials (PVC, PE, PPR, etc.) and diameters.
3. Space-Saving Efficiency
Compact Footprint: Integrate a high-pressure pump and45 testing stationswithin less than1m², optimizing lab space.
4. Robust Performance
Variable Frequency Pump: Adjusts flow dynamically to match test demands, reducing energy consumption and noise.
5. User-Centric Safety
Intuitive Interface: IPT software enables effortless parameter input, real-time status monitoring, and automated report generation (PDF/Excel).
Safety Protocols: Emergency stop, overpressure protection, and leak-proof fittings ensure operator safety.
6. Trustworthy Results
Data Integrity: Wireless remote access and multi-user collaboration tools streamline workflows, while direct integration with Pipeson™ analytics guarantees end-to-end data security.
Product Features
Smart Software Suite:
Multi-user environment with role-based access control.
Wireless remote operation via mobile/tablet.
Sample database with barcode scanning and batch import/export.
Customizable report templates (ISO/ASTM compliant).
Precision Engineering:
Stainless steel test chamber with anti-corrosion coating.
Dual-circuit hydraulic system for rapid pressure stabilization.
Self-diagnostics for fault alerts and maintenance reminders.
Ergonomic Design:
7-inch touchscreen with multi-language support (English, Spanish, German, Chinese).
Adjustable stand height and mobile caster base for lab mobility.
Accessories
PipeTesting Pro™ Software License: Lifetime updates for data analytics.
High-Accuracy Pressure Sensors: 0.05% FS accuracy (x3 units).
Quick-Connect Fittings Kit: For 16mm–160mm pipe diameters.
Spare Parts Pack: Seals, hoses, and calibration tools.
Multilingual User Manual: PDF + hardcopy (English/Spanish).
ISO 17025 Calibration Certificate: NIST-traceable calibration.
Technical Parameters
| Parameter | Specification |
|---|---|
| Pressure Range | 0–50 MPa (customizable up to 100 MPa) |
| Testing Stations | 45 (expandable to 60) |
| Pump Type | Variable Frequency Drive (VFD) |
| Power Supply | 220V/50Hz or 110V/60Hz (CE/UL certified) |
| Control System | PLC + HMI Touchscreen |
| Data Interface | Ethernet (TCP/IP), USB 2.0. Wi-Fi |
| Operating Environment | 5–40°C, ≤85% RH (non-condensing) |
| Dimensions (L×W×H) | 950mm × 850mm × 1800mm |
| Weight | 450 kg (net) |
