Fully Automatic Continuous Flow Reaction Calorimeter

Standards

SN/T 3078.1. NY/T 3784. GB 51283

Product Features:

1. Using the coefficient calibration method and flow - regulation calorimetry, it can quickly obtain the reaction heat release and heat - flow distribution, and calculate the peak temperature and temperature distribution.

2. It enables fully automatic continuous reaction process operations, with functions such as automatic sample injection, pre - heating, automatic degassing, flow control, enhanced mixing, precise temperature control, and multi - point temperature measurement.

3. The high - performance programmable circulating water bath can be set to automatically complete pre - heating and temperature control of the reaction environment.

4. It is safe and efficient. The system can operate unattended and automatically complete data recording and analysis.

5. Reactors can be replaced or added. Different materials of reactors can be selected according to actual needs.

Technical specification:

Sample Flow Range

(0.01-50)mL/min

Number of Sample Channels

2 (Expandable)

Sample Flow Accuracy

<±0.5%

Sample Flow Resolution

0.01mL/min

Sample Pressure Pulsation

0.05MPa

Jacket Temperature Range

(0-85)°C

Jacket Temperature Accuracy

±0.05°C

Pipeline Temperature Range

(-180-260)°C

Temperature Sensor Temperature Range

(-50-200)°C

Number of Temperature Points

Reaction lines: 6. preheating line: 1. jacket temperature: 1. Can be flexibly increased or decreased according to the experimental situation
