Electrode tortuosity tester & diaphragm ion conductivity tester
Standard
Electrode Tortuosity Analyzer:
ASTM E1970-21 (Electrochemical Impedance Spectroscopy)
ISO 18516 (Conductive Coatings – Resistivity Measurement)
Separator Ionic Conductivity Tester:
IEC 62660-2 (Secondary Lithium-Ion Cells – Performance Testing)
ASTM D5402 (Conductivity of Ionic Solutions)
Universal Compliance: RoHS, CE, and REACH certified
Product Advantages
Electrode Tortuosity Analyzer
3D Microstructure Imaging:
Sub-micron resolution CT scanning reveals tortuosity pathways in 3D.
Automated tortuosity factor calculation (τ < 1.2 for ideal structures).
Non-Destructive Analysis:
X-ray-free optical tomography preserves sample integrity.
60-second full-volume scan for rapid R&D iteration.
Multi-Material Compatibility:
Tests dry electrodes, slurry-coated foils, and solid-state composites.
Separator Ionic Conductivity Tester
Ultra-Wide Conductivity Range:
Measures 0.01 mS/cm to 20 mS/cm for ceramic/polymer hybrids.
AC impedance spectroscopy up to 10 MHz.
Automated Liquid Handling:
Programmable electrolyte injection (0.1–100 μL precision).
Self-sealing sample chamber prevents evaporation.
Temperature-Controlled Testing:
-20°C to 80°C Peltier stage with ±0.1°C stability.
Product Features
Electrode Tortuosity Analyzer
Laser-Guided Alignment: Ensures precise sample positioning (±2 μm accuracy).
AI-Powered Analysis: Machine learning identifies critical pathways in 3D datasets.
Multi-Scale Imaging: Combines macro (cm-scale) and micro (μm-scale) views.
Open Architecture: Compatible with third-party SEM/FIB data.
Separator Ionic Conductivity Tester
Non-Contact Electrodes: Graphene-coated sensors eliminate polarization effects.
Dielectric Spectroscopy: Analyzes ion mobility under AC/DC bias.
Auto-Calibration: NIST-traceable standards integrated into testing cycle.
Glovebox Compatibility: Hermetic design for oxygen/moisture-sensitive materials.
Technical Parameters
| Parameter | Electrode Tortuosity Analyzer | Separator Ionic Conductivity Tester |
|---|---|---|
| Measurement Range | τ = 1.01–5.00 | 0.01 mS/cm – 20 mS/cm |
| Accuracy | ±2% (τ ≤ 3.00) | ±0.5% of reading + 0.005 mS/cm |
| Resolution | 0.01 μm (3D voxel) | 1 nS/cm |
| Test Speed | 60 sec/sample | 120 sec/sample (including stabilization) |
| Temperature Range | 20°C–200°C (optional upgrade) | -20°C–80°C |
| Interface | USB 3.2. GigE Vision | Ethernet, Wi-Fi 6. Bluetooth 5.3 |
| Dimensions | 550mm (W) × 500mm (D) × 600mm (H) | 400mm (W) × 350mm (D) × 250mm (H) |
| Weight | 95 kg (net) | 30 kg (net) |
