Infusion Apparatus Leakage Positive Pressure Tester
M102 Infusion apparatus leakage positive pressure tester, It is suitable for the measurement of the airtight of injector for medical purpose, and it can accurately measure whether the sealing performance of the injection syringe meets the specified requirements.
Standards compliant：
GB 8368-2005: Chinese National Standard "Disposable Infusion Sets for Single Use — Gravity Infusion Type", which mandates performance requirements (including airtightness) for medical infusion devices, directly guiding the tester’s validation of syringe/seal integrity.
Major Features
Touch-tone control panel
The tester adopts touch-tone and LED digital display meter, and the test pressure can be set arbitrarily, with wide application range, stable performance, and long service life.
Test time can be set arbitrarily
The tester has a timing module, and the test time can be set arbitrarily to meet different test requirements.
Air Leaknge Teater far Seoitive Pressre
Flexible and compact design The flexible and compact design makes this tester easy to assemble, which can be installed to test from the lab to the production line at anytime, anywhere.
Field Application
M102 Infusion apparatus leakage positive pressure tester, Itis suitable for the measurement of positive pressure airtight of medical infusion apparatus, blood transfusion devices, infusion needles, anesthesia bag filters, pipelines, conduits, quick joints, and etc. It can accurately measure whether the sealing performance of injection syringe meets the specified requirements.
It is applicable to the performance verification of new products, quality control of the production department, and the of material properties for the third-party testing organization, the product performance verification laboratory, and the quality and technical supervisiondepartment, etc.
Technical Parameters
|
Control mode: automatic |
Weight30kg |
|
Test pressure :- 10KPa~ -30KPa |
Power supply:220V 50Hz |
|
Pressure accuracy: ±0.5KPa |
Appearance size: 40cmX45cmX45cm |
|
Test time:1-16S/adjustable |
Usage:
put the instrument horizontally on the test platform ;
the Vessel to be tested will be installed on the outfall Connector;
Plug the power plug into the distribution board, and the power socket on the distribution board must be grounded reliably.
Operating instructions
