Catheter Guidewire Friction meter

Test standard

YY/T1536-2017.ISO 11070

Test principle

The sample is clamped between the two chuck of the fixture, the two chuck do relative movement, and the puncture or opening force test will be carried out through the special chuck. Through the force sensor located on the moving clamp head and the displacement sensor built in the machine, the change of force value and displacement in the test process is collected, and the corresponding force value data is obtained.

Technical parameter

1. Test range: 0-500N (50N, 100N, 200N, 1000N other ranges are optional)

2. Measurement accuracy: 0.5 level

3. Travel: 800mm

4. Test speed: 0.5-500mm/min stepless transmission

5. Displacement accuracy: 0.01mm

6. Sample quantity: 1 piece

7. Chuck size: 0-30mm

8. Shape: 450mm(L)× 500mm(B)× 1500mm(H)

9. Weight: 75kg
