Automatic freezing point pour point cold tester

The automatic freezing point pouring point Freezing point tester is suitable for petroleum, biological, chemical and other fields, and is used to accurately determine the freezing point/pouring point/freezing point/turbidity point of jet fuel, biofuels, lubricating oil, coolant and other substances.

Reference standard:

SH/T 0770. ASTM D5972

SH/T 0771. ASTM D5949

GB/T 510

ASTM D5773

Product features:

1) Using advanced automatic phase conversion method and pressure pulse method test, more accurate and efficient

2) The sample size is small, the test cost is low and the pollution is small

3) Built-in Sterling temperature control module, no need for external cooling, high integration

4) The frame-by-frame scanning dynamic comparison algorithm was used to accurately judge the phase transition state of the sample

5) Preset standard test methods, you can freely choose test items

6) Real-time display of temperature and optical signal strength curve, the test process is more intuitive

7) Automatic selection of pulse pressure, automatic heating of sample cup, easy cleaning:

8) Key components are internationally renowned brands to ensure long-term stable operation

9) Hierarchical user management, can achieve different levels of account management control

10)USB interface plug and play, optional thermal printer, easy data management

11)7 inch color touch screen, support Chinese input, intuitive and simple operation

Technical parameters:

Operating Environment

(030)℃,85%RH

Temperature Range

(-8055)℃

Rising Rate

(15±5)℃/min, (10±0.5)℃/min, (1.5±0.1)℃/min

Temperature Detection Accuracy

±0.1℃

Sample Volume

0.15mL

Measurement Method

Freezing point, turbidity point: automatic phase conversion method;

Pour Point Test Interval

Pouring point, condensation point: automatic pressure pulse method

Repeatability

1℃ or 3℃

Reproducibility

Freezing point: 0.69℃;

Storage Space

Pouring point: 1.6℃@1℃, 2.2℃@3℃; condensation point: 2.0℃; Turbidity point: 1.3℃ Freezing point: 1.3℃; Pouring point: 3.2℃@1℃, 2.2℃@3℃; condensation point: 4.3℃; Freezing point: 4.0℃; Freezing point: 4.3℃; Pouring point: 2.2℃@3℃; Freezing point: 1.0℃ 3℃;

Interface

Freezing point: 2.0℃;

Power Supply

Turbidity point: 1.3℃

Power

Freezing point: 1.3℃;

Dimensions

Pouring point: 3.2℃@1℃, 3.8℃@3℃;

Weight

Freezing point: 4.0℃;
