Molten metal splash penetration resistance analyzer

Standard

  • ISO 9185(Protective Clothing - Assessment of Resistance to Molten Metal Splash)
  • ASTM F955(Standard Test Method for Evaluating Heat Transfer Through Materials for Protective Clothing Upon Contact With Molten Substances)
  • EN ISO 11612(Protective Clothing - Performance Requirements for Clothing to Protect Against Heat and Flame)

Product Advantages

  1. Precision Molten Metal Delivery
    • Programmable crucible system delivers molten metal (iron, aluminum, zinc) with ±2°C temperature accuracy, simulating industrial splash scenarios.
  2. Automated Safety Protocols
    • Integrated shielding, emergency coolant system, and laser-guided drop placement minimize operator risk during testing.
  3. High-Speed Imaging
    • 1,000 FPS camera captures penetration dynamics in real time, providing visual evidence for compliance reporting.
  4. User-Centric Operation
    • 10.1-inch touchscreen with multilingual interface (English, German, Chinese, Korean) and AI-powered test result analysis.
  5. Low Cost of Ownership
    • Energy-efficient design reduces power consumption by 25%, with recyclable crucible liners minimizing waste.

Product Features

  • Multi-Metal Testing:
    • Supports iron (1,400–1,600°C), aluminum (700–750°C), and zinc (420–450°C) for versatile hazard simulation.
    • Adjustable drop height (0.5–2.0m) and volume (1–50g) to replicate varying splash intensities.
  • Real-Time Monitoring:
    • Thermal imaging and pressure sensors track penetration events, with cloud-based data storage for ISO-compliant reporting.
  • Safety First:
    • Explosion-proof enclosure, interlock system, and automatic crucible ejection prevent operator exposure to hazards.
  • Modular Expandability:
    • Optional upgrades for high-speed video analysis, multi-angle impact testing, and third-party software integration.

Technical Parameters

ParameterSpecification
Temperature Range Up to 1,600°C (±2°C accuracy)
Metal Compatibility Iron, Aluminum, Zinc, Copper
Drop Height Range 0.5–2.0m (adjustable)
Drop Volume Control 1–50g (±0.1g accuracy)
Data Acquisition Rate 10,000 Hz (thermal/pressure sensors)
Power Supply 380V/220V AC, 50/60Hz, 4.5kW
Dimensions (L×W×H) 1.5×1.2×2.0 m
Weight 300 kg
Operating Environment 5–40°C, ≤75% RH (non-condensing)
