New energy wire and cable extrusion & scraping tester
Product Introduction:
The new energy wire and cable extrusion jacket scratching tester is used to test the scratching resistance of the plastic jacket with an outer diameter of 30mm and above.
Standard:
JB/T10696.6-2007Test methods for mechanical and physical properties of wire and cable Part 6: Extrusion jacket scraping test
GB/T 12706.3-2008:19.17. GB/T 33549. CQC outer sheath scraping test
Parameters:
1.Angle iron scraper curvature radius:R1.5mm(standard requirements: greater than 1mm, less than 2mm)
2.shaving stroke:{>}600mm
3.grinding speed:(150-300)mm/s adjustable
4.grinding times:9999 times can be set
5.test diameter range:10mm≤D{<}90mm
6.weight weight:1N, 5N, 10N each 1. 20N, 100N each 2. 50N3 (line diameter of 90mm or more optional :50N, 100N each one
7.automatic reversing, scraping speed uniform
8.test environment temperature monitoring:the test environment temperature is not in the range of 20+5℃C, the testing machine can not start
9.Power supply:AC220V 50/60Hz 1KW
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
