Automotive connector insertion and withdrawal force testing machine
Standards
ISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
Main parameters
1. load: 50kg, 20Kg, 10Kg, 5Kg optional
2. minimum resolution: 0.01
3. the maximum measurement height: 150mm
4. the minimum fine-tuning distance 0.01mm (0.001mm)
5. measuring speed range: 0-200mm/min
6. XY axis movement range: 0-75mm
7. Transmission mechanism: rolling screw
8. Motor: servo motor
Equipment composition
1 test machine
1 industrial computer mainframe
One 17 "LCD monitor
Control software 1 set
1 printer
Large X-Y mobile station One X, Y mobile station)
1 set of self-centering device for the whole row of insertion and removal
Multi-functional fixture 2 sets
Clip mouth 2 sets
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
