Spray Rating Tester

•

Standards:

ISO 4920. BS EN 24920. BS 3702. GB/T 4745. AATCC 22. M&S P23. NEXT 23

Applications:

Spray Rating Tester is used to determine the surface wetting resistance of fabrics.

Information:

The Spray Testercomprises a metal framework allowing distilled water to be sprayed through a nozzle onto a test specimen at 45° and 150mm below. The appearance of the specimen is compared against an optional photographic scale to rate.

Features:

1. The instrument structure is simple, mainly by the main frame, funnel, nozzle, sample holder and sample holder;

2. Nozzle have a total of 19 aperture evenly distributed, the aperture required by the standard custom. 250ml of water poured into the funnel can flow out of the nozzle within 25-30s;

3. The racks on the upper edge of the racks are at a 45 ° angle to the horizontal;

4. The center of the upper edge of the sample holder ring, ie the distance from the center of the sample to the nozzle, is 150 mm.

Parameters:

1. Structure: stainless steel;

2. Surface treatment: painting;

3. Dimensions: 230 × 250 × 500mm (length × width × height);

4. Weight: 5kg (11lb).

Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
