Instrument powder Coating

Introduction

It is made of polyester resin and epoxy resin as the main base materials, and has the excellent decorative, mechanical properties and good corrosion resistance of epoxy and polyester.

Location	China
Business Type	Manufacturer, Exporter
Brand	Standard
Certificate	ACS,NSF,QUALICAOT,WRAS,KTW
Payment and Delivery Terms	30% advance payment, 70% before delivery
Minimum Order Quantity	100kg
Price	Negotiable
Delivery Time	7-10 days
Payment Method	T/T,L/C

Brief Description

This product is made of polyester resin and epoxy resin as the main base materials, combining the excellent decorative properties, mechanical properties and good corrosion resistance of epoxy and polyester.

Features

Excellent mechanical properties (impact resistance, hardness, toughness, adhesion, etc.)

Good leveling and gloss

Strong corrosion resistance

Application areas

Household appliances, communication equipment units, indoor fitness equipment, tool boxes, filing cabinets, shelves, lamps, etc.

Product series

Standard curing type and low temperature curing type are available

Various gloss and colors can be made

Various texture products such as flat surface, art texture, metal effect, antique can be made

Technical parameters

Mechanical properties

Test items	Test standards	Performance indicators
Pencil hardness	GB/T6739-1996	>H
Adhesion	GB/T9286-1998	Grade 0
Bending	GB6742-86	3mm
Impact	GB/T1732-93	50kg.cm
Cupping	GB9753-88	>6mm

Corrosion resistance

Test items	Test standards	Performance indicators
Salt spray resistance	GB/T1771-91	No change in coating after 500 hours, single-side isolation at specification <2mm
​Moisture and heat resistance	GB/T1740-79	>500 hours slight gloss loss, ≤Grade 1

Note: The above parameters are laboratory data for reference only. Actual indicators are related to factors such as customer environment, equipment, materials, pretreatment, and spraying process.

Powder performance

Specific gravity: 1.1~1.8g/cm³

Application conditions

Pretreatment: phosphating, chromating

Coating: Suitable for high-voltage electrostatic spraying, friction electrostatic spraying, electrostatic fluidized bed spraying, fluidized bed dipping

Curing conditions:

140℃ at 30 minutes

180℃ at 15 minutes

200℃ at 10 Minutes

Can also be designed according to customer needs

Packaging

Carton packaging

Net weight 20kg/box

Lined with polyethylene plastic bag

Storage conditions

Store in a dry, ventilated room below 30°C

Avoid direct sunlight

Under this condition, the powder can be stably stored for 6 months

Safety and health

• All raw materials of powder coatings do not contain toxic substances.
• No toxic gas is released during baking.
• Avoid inhalation of dust during use.
• Operators should wear dust masks.
• Minimize long-term contact between skin and powder.
• Paint attached to the skin can be washed with soap.

If you're ready to take the next step or Request Free Samples, Leave your message below and we’ll reply soon. 20+ years of chemical manufacturing & export experience, a partner you can trust.
