Epoxy Anti-Corrosion Powder Coating for Firefighting Pipes
Product Introduction:
This product is formulated using linear phenolic epoxy resin, polyurethane-modified epoxy resin, and advanced curing agents, designed and manufactured based on the latest formulation concepts. It features high reactivity, strong adhesion, high cross-link density, and excellent resistance to chemicals, solvents, cathodic disbondment, impact, and high temperatures.
Product Usage:
For internal and external anti-corrosion coatings of water supply pipes used in firefighting systems.
Product Features:
-
Excellent adhesion to the substrate.
-
Strong anti-corrosion capability.
-
Good leveling, high gloss, and dense coating.
-
Superior high-temperature cathodic disbondment resistance.
-
Extremely strong flexibility, capable of passing the 4/5 flattening and post-grooving tests.
-
Good performance in withstanding high and low temperatures.
-
Strong resistance to boiling water.
Powder Performance:
| Property | Specification | Notes |
|---|---|---|
| Adhesion | Excellent | |
| Corrosion Resistance | Superior | |
| Leveling | Good, high gloss, dense coating | |
| Cathodic Disbondment Resistance | Excellent at high temperatures | |
| Flexibility | Extremely strong, passes 4/5 flattening and post-grooving tests | |
| Temperature Resistance | Good performance in high and low temperatures | |
| Boiling Water Resistance | Strong resistance |
Curing Conditions:
| Property | Specification | Notes |
|---|---|---|
| Temperature | Referenced to workpiece temperature | Deviations may affect performance |
| Heating Method | Medium-frequency heating or other heating methods |
Application Parameters:
| Parameter | Specification | Notes |
|---|---|---|
| Applicable Equipment | Frictional charging spray, corona electrostatic spray, dip coating | |
| Film Thickness | 150-450um | Adjustable according to workpiece requirements |
Health and Safety:
| Property | Specification | Notes |
|---|---|---|
| Toxicity | Non-toxic | |
| Flammability | Non-flammable | |
| Regulation | GB15607-1995 | Coating operation safety regulations |
Precautions:
| Item | Specification | Notes |
|---|---|---|
| Outdoor Use | Not recommended | May cause fading and chalking |
| Surface Preparation | Oil-free, water-free, surface treatment to Sa21/2 level (GB/T8923), anchor pattern depth 40-100um, clean surface from dust and abrasives | |
| Preheating | Temperature controlled between 180-240°C | |
| Storage | Ventilated, dry, below 30°C, away from heat sources, corrosive chemicals, and solvents, avoid strong light, maximum stack height 4 layers, avoid long-term pressure, keep packaging sealed | |
| Curing Temperature | Preheat steel pipe surface to above 200°C for better curing completion rate |
Compliance Standards:
GB/T 5135.20-2010 “Coated Steel Pipes for Automatic Sprinkler Fire-Protection Systems”;
CJ/T 120-2008 “Plastic-Coated Composite Steel Pipes for Water Supply”
