ZC Type Mechanical Rotary Blow Flat Bag Filter
ZC Type Mechanical Rotary Blow Flat Bag FilterIntroduction:
The dust collector adopts a circular body structure with uniform force, good anti-knocking performance, compact structure, high-pressure blower and blower cleaning, and is not limited by the air source condition, and uses the resistance to automatically control the blowback dust to save energy and prolong the use of the bag; Regional indoor installations can be installed outdoors in other areas, and can be widely used in many sectors such as machinery, foundry, mining, smelting, building materials, and food chemical.
Users should pay attention to the high temperature, high concentration, fine particles of dust should choose A type, and vice versa B type is appropriate, such as the concentration of more than 15g/m3 should be preceded by a cyclone dust collector(For coarse nuclear dust can be relaxed as appropriate).
ZC Type Mechanical Rotary Blow Flat Bag Filter Model indication:
144ZC-II-500-ANP570 rotary counter blowing flat bag filter.
Item 1: 144 is the number of filter bags (only)
Item 2: ZC refers to the beginning of the pinyin of the rewinding blow, in which "Z" refers to the beginning of the Chinese pinyin of "turning" and "C" refers to the beginning of the Chinese pinyin of "blowing".
Item 3: II- refers to the design number.
Item 4: 500 refers to the length of the bag (meters).
Item 5: According to the different filter speed V, the dust collector is divided into A type and B type size. A type size is used for an air volume of V=1.0~1.5/min. Type B size is used for V = 2.0~2.5/minute air volume.
Item 6: According to the rotating wind direction of the population, it can be divided into N-rotation and S-rotation. N indicates that the inlet rotates counterclockwise, S indicates that the inlet rotates clockwise, and the serialized drawings are rotated counterclockwise (that is, N-rotation).
Item 7: According to the form of the outlet duct, there are two kinds of exits: the flat exit and the lower exit. P means the flat exit, X means the lower exit, and the serialized drawings are drawn as flat exits (that is, P-type).
Item 8: 570 is the nominal filter area (m3).
Hebei Ou Tai Environmental Protection Equipment Co., Ltd. is the best dust collection system manufacturer, we have industrial dust collection systemsand we provide baghouse dust collector for sale, bag house for sale and etc. Want to know more, please contact us.
Отправить запрос, связаться с поставщиком
Другие товары поставщика
 |
Electrostatic Precipitator (ESP) Dust Collector | An electrostatic precipitator dust collectoris a device that uses an electric field to separate the solid or liquid contaminants present in the gas... |
 |
Filter Bag Cage | Dust removal frame, also known as dust bag cage, is an indispensable accessory for bag filter, used as a frame of bag supporting cages. It can be c... |
 |
High Temperature Fiberglass Filter Bag | The glass fiber continuous filter cloth is composed of continuous glass fiber yarns for both warp and weft yarns. The specially processed and manuf... |
 |
The Electromagnetic Valve | Electromagnetic pulse valves (also known as diaphragm valves) are compressed air "switches" for pulse bag filter dust cleaning systems. By the cont... |
 |
Cyclone Separation Dust Collector | CLK Diffusion Cyclone Dust Collector Details of cyclone collector CLK diffusion cyclone dust collector is suitable for supplementing dry non-fibrou... |
Похожие товары
 |
Rubber Bladder for ST High Pressure Accumulator NXQA-10/31.5 for Pacitan power (test) | Продавец: Dongfang Yoyik Engineering Co., Ltd | Rubber Bladder for ST High Pressure Accumulator NXQA-10/31.5 As a leading domestic supplier of po... |
 |
vertical screw pump HSNH280-54A for Cirebon power (test) | Продавец: Dongfang Yoyik Engineering Co., Ltd | vertical screw pump HSNH280-54A YOYIK, with advanced technical equipment and rich industry experi... |
 |
