Features and Benefits

1.Full-spectrum precise reproduction

a 4500 Wwater-cooledxenon arc lamp and SUS 304 mirrorworkroom, the spectral range covers ultraviolet, visible light and infrared. The adjustable irradiance is 35—150 W/m², ensuring that the experimental results are highly consistent with the real sunlight environment.

2.Wide temperature and humidity controllable environment

The temperature can be precisely adjusted from room temperature to 100 °C (±0.5 °C), and the humidity range covers 50%—98% RH (±2% RH), meeting the needs of various harsh aging and environmental stress tests.

3.Programmable water spray system

Supports multi-segment program settings, simulating different working conditions such as dew, condensation and intermittent rainfall. The spray cycle, duration and flow rate can be precisely configured through the touch screen PID control.

4.High-throughput sample testing

The rotating sample holder can accommodate up to 42 samples at a time, combined with the customizable volume, achieving uniform irradiation and high-efficiency batch testing.
