Building Material Radiant Panel Test Machine

•

This machine is designed according to AS/NZS 1530.3;

Thedeviceviaagasradiantplatetoheatsamplesandwithheatflowmetertocalibration;Testsampleswere placed inaverticalposition, neartheradiationplate,exposedinaclearareacalibratedradiationflux. Closetothepilotflame isassembled withtestsample, but not in contact withthetestsample.

After ignition, to record the ignition time, flame propagation time, heat release integral, Smoke Release etc.

Standard

AS/NZS 1530.3

Feature

1.All structural components are made of stainless steel, nice appearance, corrosion resistance;

2.Sample fixture could be movable to adjust the distance to radiant panel.

3.Ignition sources: radiation plate and two pilot flame burners;

4.One pilot flame burner is fixed before the sample at 15mm

from front face of sample and 50mm above the centre of the samples. And the other burner could be moved before the sample.

5.Flame height is controlled by imported flow control meter.

6 , Samples size: 710mm x610mm;

7.Stainlesssteelhoodandfluetocollectthesmokeofspeciments. Hoodsize: 1140mmx1140mm;smoketubeis

dia.305mm;

8 , Radiant panel size: 300mm x300mm; With porous fire-brick surface.

9.Radiationplatetemperatureprobe: preventflamesturnedtheheatradiatingplaterearside;

10. Precise gas and air flow control to realized the radiant panel heatadjustment.

11. ProvideHeatfluxsenorfixturetocalibratetheradiationlevelaccordingtostandardrequest2.4kw/;

12. Two shield could be removed as standardrequest.

13. 19 "rack to measure the flame spread rate analysis, critical flow, heat releaserate

14. Provide an exhaustfan.

Optical system

1. The optical system comprising a light source color temperature is 2900 ± 100 K incandescent, light receiving silicon photodiode with an optical path test shutter, 0% and 100%, to facilitate the use of calibration;

2. Imported light battery module measuring light attenuation. The system automatically calculates and generates a light transmittance curve translucent; printable Scribble

3. One button automatic and five level (0.25%,50%,75%,100%)calibration system by computer.
