Cross scratch tester - lab instrument

Get a quote：

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Email: serving@qinsun-lab。com

We are a professional testing instrument manufacturer offering complete laboratory testing solutions. If you need more information or wish to explore our full range of test equipment, please contact us for details and technical support.

Standards

Automotive Standards: PV 3952. Ford BN 108-03. BMW 0180. DAF KEUR 00824-401. GME 60401. GM 14829. Jaguar-Landrover TPJLR.52.00. GM N 14688

General Standards: 8350Z-SDA-9000. NES M M0159

Product Advantages

Unmatched Precision & Reliability

High-precision stepper motor and rail transmission system minimize operational noise while ensuring uniform movement and long-term durability.

Rail-guided positioning guarantees ±0.01mm accuracy, critical for repeatable cross-cut adhesion tests.

Versatile Customization

Interchangeable Weight System: Adjustable load range (5–50N) accommodates varied testing protocols, with customizable pressurization options.

Modular Fixture Design: Spin-type sample clamping ensures secure fixation without slippage; replaceable fixtures adapt to friction head dimensions for diverse test areas.

Intuitive Operability

" LCD touchscreen supports English/Chinese interfaces, enabling effortless parameter setup (stroke, speed, grid count) and real-time data monitoring.

Pre-programmed test suites align with major international standards, reducing setup complexity.

Industrial-Grade Durability

Robust construction withstands high-frequency laboratory use, maintaining calibration stability over 10.000+ test cycles.

Product Features

Advanced Control System:

LCD interface displays test progress, grid spacing (1mm/2mm options), and cutting speed (10–100mm/s adjustable).

Multi-language support enhances global usability.

Precision Engineering:

Horizontal/vertical rail transmission eliminates backlash, ensuring flawless cross-hatch pattern execution.

Quick-release friction heads simplify transitions between test configurations.

Adaptive Testing Capabilities:

Flexible fixtures integrate with imported scratch heads, enabling compliance with automotive, aerospace, and consumer goods standards.

Adjustable scratch spacing (0–2mm) caters to materials with varying surface textures.

Ergonomic Design:

Compact footprint (400x350x300mm) saves lab space while accommodating samples up to 200x150mm.

Tool-free sample mounting reduces setup time by 40% compared to traditional clamps.

Technical Parameters

Specification	Details
Load Range	5N, 10N, 20N, 50N (customizable up to 100N)
Cutting Speed	10–100 mm/s (adjustable in 1mm increments)
Grid Spacing	1mm, 2mm (0–2mm adjustable)
Sample Size	Max. 200mm (W) x 150mm (D)
Power Supply	220V/50Hz, 110V/60Hz (CE-certified)
Dimensions	400 (L) x 350 (W) x 300 (H) mm
Weight	25 kg (net)
Operating Environment	15–35°C, ≤85% RH (non-condensing)
