Impact Testing Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Impact Testing Machine is suitable for a wide range of material testing applications:
Aerospace Materials: Test aircraft coatings and structural materials for impact resistance.
Railway Components: Evaluate durability of railcar coatings and interior panels under sudden mechanical stress.
Automotive Coatings: Assess stone-chip and high-speed particle impact resistance on vehicles.
Paint and Coating Development: Optimize formulation for durability and adhesion under impact loads.
R&D and Quality Control: Perform controlled energy impact tests for material validation and certification.
Typical test products include aircraft panels, railway interior panels, automotive paint samples, and rigid plastic components.
Standards
The system supports compliance with international and automotive material standards:
ISO 6272‑1:2011 – Paints and varnishes – Impact resistance tests – Part 1: Large-area falling-weight test.
ISO 6272‑2:2011 – Paints and varnishes – Impact resistance tests – Part 2: Small-area falling-weight test.
ASTM D2794‑04(2022) – Standard test method for resistance of coatings to impact.
ASTM D5420‑21 – Test method for rigid plastic impact performance (falling-weight method).
GB/T 14123‑2012 – Mechanical impact testing machine performance characteristics.
GB/T 20624.1‑2006 – Paints and varnishes – Large-area falling-weight impact test.
GB/T 20624.2‑2006 – Paints and varnishes – Small-area falling-weight impact test.
ISO 20567‑1 – Road vehicles – Automotive materials resistance to stone-chip impact.
SAE J400 Series – Impact testing and material performance standards.
ASTM D3170 – Stone-chip impact performance test method.
GMW14668‑3.4.9 – GM stone-chip impact requirements.
Parameters
| Parameter Category | Details |
|---|---|
| Impact Device Dimensions | 270 × 600 × 200 mm (W × H × D) |
| Impact Device Weight | 10 kg |
| Impact Energy | 3 – 140 J (at 6 bar maximum) |
| Energy Adjustment | Via controller, adjustable within range |
| Data Sampling Rate | 50 kHz |
| Display | 4.3" touch screen, 480 × 272 pixels |
| Data Storage | SD card |
