100-V2 steam generator performance tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The 100-V2 Steam Generator is designed for automotive thermal shock testing, capable of generating precise steam conditions required by major OEM thermal shock specifications. It provides controllable steam flow and pressure for repeatable testing of automotive components under thermal stress.
Application
(1) Automotive Thermal Shock Testing: Simulates rapid temperature changes on vehicle components using controlled steam injection.
(2) OEM Compliance Testing: Meets Ford, GM, and FCA thermal shock specifications for component validation.
(3) R&D and Quality Control: Evaluates thermal resistance and durability of automotive parts during design and production.
(4) Material and Component Verification: Supports verification of seals, coatings, and heat-sensitive parts under thermal stress.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | STD-100-V2 |
| Water Flow Rate | 2.7 ± 0.1 L/min |
| Steam Dynamic Pressure | 37.9 ± 1.9 kPa |
| Tubular Nozzle | Inner diameter 12.5 ± 0.3 mm, length ≥100 mm, non-corrosive material |
| Burner Type | Adjustable gas/electric |
| Hose Compatibility | High temperature/high pressure steam hoses |
| Dynamic Head Clamp | STD-DHF-1 |
| Measurement Distance | 25 mm from nozzle |
| Measurement Tube Bore | 4.7 mm |
| Power Supply | AC 220V / 50Hz (standard) |
| Operating Environment | Laboratory/Automotive test bench |
